- Page 1 GUIDES FAN BLADE REPLACEMENT MODELS : TK3000 – TK3000H TK6000 – TK6000H TK9000 – TK9000H www.tecoonline.com www.tecous.com...
- Page 2 EQUIPMENT Key for nut (10) Key for nut (10) Screw-drivers Fan Blade (spare part) www.tecoonline.com www.tecous.com...
- Page 3 If this are not performed properly, they can cause electric shock, burns and fires WARNING! TECO S.r.l. decline any responsibility in case of damages caused by a wrong installation Disconnect the chiller from power supply. Never touch internal part or dismount chiller when it is connected to power supply to avoid potential electric shock.
- Page 4 STEP n. Using the screw-driver, remove the screws indicated in the picture here below (n°16 screws) www.tecoonline.com www.tecous.com...
- Page 5 STEP n. Disconnect ground wire from the cover Remove the cover www.tecoonline.com www.tecous.com...
- Page 6 STEP n. Remove the conveyor top cover: take out the 6 screws (shown in the picture) using the small screw-driver www.tecoonline.com www.tecous.com...
- Page 7 STEP n. Remove the 2 screws mounted alongside the condenser, using the screw-driver (as shown in the picture). www.tecoonline.com www.tecous.com...
- Page 8 STEP n. Move the condenser by pulling on the free side. Stop when you are sure you can turn the nut of the fan. www.tecoonline.com www.tecous.com...
- Page 9 STEP n. Replace the broken fan blade with a new one: take out the nut using the key. Please be careful when doing this operation: the fan blade material is not too strong and the new component can break. Re-assemble the condenser (2 screws on one side) and the conveyor (6 screws on the top part) as before.
