Appendix
Ethernet Cables
RJ45 Color
Pin
1 Green
2 Green/White
3 Orange
4 Blue
5 Blue/White
6 Orange/White
7 Brown
8 Brown/White
System Board View and Layout
You can download the board dimensions and case design files (PDF and DXF) from www.routerboard.com
RouterBOARD Groove Series User's Manual
Function Function
(100Mbit) (1Gbit)
TX+ Data Data A+
TX‐ Data Data A‐
RX+ Data Data B+
‐ Data C+
‐ Data C‐
RX‐ Data Data B‐
‐ Data D+
‐ Data D‐
RJ45 pin for Straight cable
(MDI, EIA/TIA568A)
1
2
3
4
5
6
7
8
RJ45 pin for Crossover cable
(MDI‐X, EIA/TIA568B)
3
6
1
4
5
2
7
8
7
