wAP ax
wAP
ax, wAPG-5HaxD2HaxD
Safety Warnings
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for
preventing accidents. The installer should be familiar with network structures, terms, and concepts.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that
the Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product is intended to be mounted outdoors on a pole but can also be installed
beginning installation. Failure to use the correct hardware and configuration or to follow the correct procedures could result in a hazardous situation for
people and damage to the system.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your
own risk!
The socket-outlet shall be installed near the equipment and shall be easily accessible.
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.
To avoid contamination of the environment, separate the device from household waste and dispose of it in a safe manner, for example, in designated
areas. Become familiar with procedures for properly transporting the equipment to designated collection points in your area.
This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take
adequate measures
Exposure to Radio Frequency Radiation:
uncontrolled environment. This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the
general public.
Quickstart
Make sure your ISP allows hardware change and will issue an automatic IP address;
Open the bottom lid;
Connect the device to the included PoE injector with an Ethernet cable to the
Connect the data end of the PoE injector to the computer;
Connect the power adapter to the PoE injector;
Navigate to the network connections section on your computer and locate the wireless network named "
ck the wireless passwords on the sticker)
Configuration should be made via a wireless network using a mobile application or you can use the
/WinBox
;
Download and open
 "
This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an
;
WinBox" and
,

choose the
  "Neighbors"
indoors. Please read the mounting instructions carefully before

"data+power"
 tab to find the device;

end;
MikroTik-...
". Proceed to connect to it (che
WinBox"
 "
configuration tool
 https://mt.lv

Advertisement

loading
Need help?

Need help?

Do you have a question about the wAP ax and is the answer not in the manual?

Questions and answers

Summary of Contents for MikroTik wAP ax

  • Page 1 Safety Warnings Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing accidents. The installer should be familiar with network structures, terms, and concepts.
  • Page 2 Mounting The device can be mounted in several ways: wall, ceiling, pole or it can be placed in specially designed MikroTik holder which comes with the package. The package includes a drill hole template with instructions, to help you with the Ethernet cable installation and attachment to a ceiling or a wall. The package also includes a steel bracket to put on the other side of a dropdown ceiling tile and two screws and wall anchors.
  • Page 3 Guide Ethernet cable through the opening and connect to the Ethernet port. Close bottom latch and secure with a screw.  It's recommended to secure Ethernet cable to the pole using zip ties. With the distance from the device approximately 30 cm. Mounting unit on the wall: Use included a template to mark spots for drilling holes.
  • Page 4 A Special bracket is included in the package to mount on the drop ceiling. As it consists of two parts, to be attached on both sides of the ceiling tile. Use the template to mark spots for holes. Place both mounting brackets on the spot. Secure them together using screws.
  • Page 5: Extension Slots And Ports

    Reassemble. Powering The device accepts power from the power jack or from the Ethernet port, both provided in the package: Direct-input power jack (5.5 mm outside and 2 mm inside, female, pin positive plug) accepts 12-57 V DC; Ethernet port accepts 802.3af/at PoE 18-57 V DC. The power consumption under maximum load can reach 9 W.
  • Page 6: Buttons And Jumpers

    Product code: wAPG-5HaxD2HaxD CPU: IPQ-5010 800 MHz CPU architecture: ARM CPU core count: 2 Size of RAM: 256 MB RAM type: DDR3L Storage: 128 MB, NAND Number of 1G Ethernet ports: 2 PoE-in: Ether1 Operating system: RouterOS (License level 4) Wireless interface model: IPQ-5010 (2.4 GHz),...
  • Page 7: Operating System Support

    Other operating systems have not been tested. MikroTik mobile app Use the MikroTik smartphone app to configure your router in the field, or to apply the most basic initial settings for your MikroTik home access point. Scan the QR code and choose your preferred OS.
