Safety Information For Installation - Ford Connected Charge Station Installation Manual

WARNING
EN-
- Immediately notify Customer Service if the charge sta-
US
tion, charging cable or the charging coupling are dam-
aged. Do not continue to use the charge station.
- Prevent the charging cable and coupling from coming
into contact with external heat sources, water, dirt, and
chemicals.
- Switch off power at the circuit breaker before installing
or cleaning.
- Do not attach extension cables or adapters to the
charging cable.
- Never clean the charge station with a high-pressure
cleaner or similar.
- Switch off the power supply before cleaning the charg-
ing sockets.
- The charging cable must not be subjected to any strain
during use.
- You must make sure that no one has access to the
charge station without reading this user manual first.
- Make sure that the charge station temperature is within
its storage temperature limits when moving, transport-
ing, or storing it.
- You are strictly prohibited from pulling the charge sta-
tion by its cable.
WARNING
When transporting the Ford Connected Charge Station ,
handle with care. Do not subject it to strong force or im-
pact, also do not pull, twist, tangle, drag, or step on the
Ford Connected Charge Station to prevent damaging it
or any of its components.
NOTICE
In addition to the safety instructions in this document,
also observe further safety instructions in any other en-
closed documents.
2
2.3

Safety information for installation

WARNING
- Only use the supplied or other appropriate installation
material.
- When the charge station is open, ESD (electrostatic dis-
charge) precautions must be taken properly to avoid
electrostatic discharge.
- When handling electrostatically sensitive boards, wear
grounded antistatic wrist straps and properly observe
ESD safety precautions. (To be used only for mounting
and connecting the loading unit. The wrist strap must
not be worn under a live charge station.)
- Electricians must be properly grounded during installa-
tion of the charge station.
- Do not install the charge station in an explosion sensi-
tive area (EX zone).
- Install the charge station in such a way that the charg-
ing cable does not block any passageways.
- Do not install the charge station in areas subject to am-
monia, or air containing ammonia.
- Do not install the charge station in a location where
falling objects may damage it.
- The charge station is suitable for indoor and outdoor
use.
- Do not install the charge station in the vicinity of water
jets, such as car wash installations, high-pressure clean-
ers, or garden hoses.
- Protect the charge station against damage caused by
sub-zero temperatures, hail, and similar.
- The charge station is suitable for use in areas without
access restrictions.
- Protect the charge station from direct sunlight. The
charging current may be reduced at high temperatures,
or charging may be disabled completely. The operating
temperature range is -40°F to +140°F (-40 °C to
+60°C).
- The installation location of the charge station should
be such that vehicles cannot inadvertently collide with it.
Protective measures must be implemented if the possi-
bility of damage cannot be ruled out.
SKML9J-10C823-BA
WARNING
- Do not put the charge station into operation if it has
been damaged during installation. A replacement will be
required instead.
- Do not touch the electronics during the installation
process.
2.4 Safety information for electrical
connection
WARNING
- You must protect each charge station with its own line
circuit breaker and residual current circuit breaker.
- A qualified electrician must make sure that all electrical
connections are de-energized before connecting the
charge station to the power supply.
- A qualified electrician must make sure that a properly
sized supply cable is used for the power connection.
- Do not leave the charge station unattended with the
cover open.
- Register the installation of your charge station with
your power supply company if this is required by law or
by any agreement.
2.5 Safety information for initial start up
WARNING
- The initial startup of the charge station must be carried
out by a qualified electrician.
- Before initial start-up, the qualified electrician must
verify that the charge station has been connected cor-
rectly.
- Do not connect a vehicle to the charge station during its
initial startup.
- Before starting up the charge station, inspect the
charging cable, charging coupler, and the charge station
for visible damage. The device must not be started up if
it has been damaged, or if the charging cable / charging
coupler has been damaged.
Ford Connected Charge Station Installation manual
