Reset Motion
E
Reset Wireless
F

Cover cap assembly

Replacing the SERVO-DRIVE switch battery

When the battery power begins to weaken, the battery display (LED) will begin to flash red�
NOTE
➢ The SERVO-DRIVE switch battery must not be recharged or discarded into fire�
16
Resets the reference run and enables a new reference run to be
started�
Press the <Reset Motion> button using a pen
(for at least 3 seconds) until the LED display flashes quickly�
Deactivates all functions: all activated SERVO-DRIVE switches of the
respective drive unit are deactivated�
Press the <Reset Wireless> button using a pen
(for at least 3 seconds) until the LED display flashes quickly�
➢ Open the SERVO-DRIVE switch and
remove the battery�
➢ Insert the new battery (type CR2032)
and close the SERVO-DRIVE switch
– note proper pole connection�
