- Page 1 SERVO-DRIVE for TANDEM Problem resolution...
- Page 2 ➢ Front height is larger than 300 mm: Install 2 Blum spacing bumpers per side. No Blum spacing bumper is ➢ Make sure that the correct Blum installed. (inner drawers or distance bumper has been used drawers with inset fronts) (adjustable distance bumper).
- Page 3 ➢ Make sure that the outlet is play on the Blum trans- turned on. former does not light. Blum transformer is not con- ➢ Make sure that the Blum power nected to the outlet. supply ➢ unit is plugged into the outlet. Blum transformer is defective.
- Page 4 We recommend the following troubleshooting sequence. Problem Possible cause Remedy Operating mode display 2 Blum transformers are ➢ Only 1 Blum transformer is permit- does not light up on connected to 1 distribution ted per distribution cable. either the Blum transfor- cable. Both Blum transformers ➢...
- Page 5 Problem Possible cause Remedy Drive unit: Selector switch ➢ Set selector switch "Mode" "Mode" is set incorrectly. to "Single." Bracket profile: Communication ➢ Equip bracket profile with com- cable is missing. munication cable (identical to distribution cable). Communication cable Pull-out will not open Cabinet is not aligned horizon- ➢...
- Page 6 Drive unit error. ➢ Reconnect drive unit and activate eject lever. ➢ Replace drive unit and activate eject lever. Julius Blum GmbH Furniture Fittings Mfg. 6973 Höchst, Austria Tel.: +43 5578 705-0 Fax: +43 5578 705-44 E-mail: info@blum.com www.blum.com...
