- Page 1 Blum SERVO-DRIVE uno Instruction leaflet www.blum.com...
- Page 2 Julius Blum GmbH is a high-quality product that simplifies everyday kitchen tasks. To safely enjoy the comfort of SERVO-DRIVE uno, please note the following: ➢ Carefully read the instruction leaflet before use. ➢ Please retain the instruction leaflet for the service life of SERVO- DRIVE uno.
-
Page 3: Safety Information
Julius Blum GmbH is not responsible for incidental or consequential damages that may arise due to non-compliance with the instruction leaflet / installation instructions. Safety information The mains plug and the Blum transformer must be easily accessib- ▀ Neither the Blum transformer nor any cabling should come into ▀... -
Page 4: Intended Use
➢ To ensure that SERVO-DRIVE uno is not triggered unintentional- ly, the switched outlet should be turned off. Intended use SERVO-DRIVE uno supports the opening of drawers and may only be used under the following conditions: In dry, enclosed rooms. - Page 5 ▀ Blum components are the only devices that should be connected to ▀ the Blum transformer. A max. of 2 drive units may be used per Blum transformer. ▀ Please make sure that the Blum distance bumper is attached. ▀...
- Page 6 The device may only be connected to a power supply that corre- ▀ sponds to the type and frequency listed on the serial tag (see Blum transformer). No damaged parts should be used.
-
Page 7: Troubleshooting
Cabinet care and cleaning WARNING Danger of electric shock! There is a danger of electric shock if fluids penetrate the Blum trans- former. ➢ Before cleaning the drive unit and/or Blum transformer, discon- nect the Blum transformer from the power. - Page 8 SERVO-DRIVE uno for LEGRABOX / TANDEM / TANDEMBOX SERVO-DRIVE uno supports the opening of drawers. Orientation diagram: bottom mount waste bin solutions SERVO-DRIVE unit pre-mounted: Attachment bracket Drive unit Transport protection Protection against dripping water Blum transformer including cable Assembly device Blum-Distance bumper SERVO-DRIVE uno for TANDEMBOX...
- Page 9 Leaning on the drawer, for example, will not open it. Blum transformer The Blum transformer provides power to the drive unit. Blum transformer function can be checked via the operating mode display (LED). Operating mode display (LED) NOTE Premature wear of SERVO-DRIVE uno due to improper use.
- Page 10 SERVO-DRIVE uno is defective. ➢ Replace the drive unit. SERVO-DRIVE uno will only Object is obstructing path. ➢ Remove the obstruction. work when pulling – not when pushing. Blum distance bumper is ➢ Attach or replace the Blum missing or defective. distance bumper.
-
Page 11: Technical Data
Spare parts can be ordered from your distributor or furniture supplier. Disposal SERVO-DRIVE uno removal may only be carried out according to the separate installation instruc- tions. All SERVO-DRIVE uno electronic components should be disposed of in a separate collection for electrical appliances as per local regulations. - Page 12 Name of kitchen owner: Address: Commission number: Fault description: Part number and batch number of the defective SERVO-DRIVE component: Part number Batch number Quantity Blum transformer: Z10N Blum-Plug-in transformer: Z10N Drive unit: Drive unit: Drive unit: SERVO-DRIVE switch: Wireless receiver:...
-
Page 14: Declaration Of Conformity
Declaration of Conformity Issuer's name: Julius Blum GmbH Issuer's address: Industriestraße 1, 6973 HÖCHST, AUSTRIA Object of the declaration: Name / Brand: Blum Products: SERVO-DRIVE Types: Z10NE020, Z10NA200, Z10NE030, Z10NA300, Z10A3000.xx, Z10ZE000, Z10ZC000, 21xA0x1, Z10C5000.xx, Z10C5007, 21P5020, 21.A00L33.xx The object of the declaration described above is in conformity with the requirements of the following docu-... - Page 15 For the commercial use of SERVO-DRIVE for AVENTOS the conformity of the furniture with the Machinery Directive 2006/42/EU should be confirmed prior to commissioning. Signed for and on behalf of: Julius Blum GmbH Hoechst, 2016-04-26 Graduate engineer (FH) Hermann Weissenhorn, Head of Engineering...
