Carmanah G Series Quick Start Manual

Traffic beacon
Hide thumbs Also See for G Series:
Table of Contents

Advertisement

Quick Links

Download this manual
G Series
TRAFFIC BEACON QUICK START GUIDE
For the SC315-G, R820-G, R829-G, and R247-G flashing beacons
84776_QSG _TRA_G-Series_RevC
Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 |
customersupport@carmanah.com
| carmanah.com

Advertisement

Table of Contents
loading

Related Manuals for Carmanah G Series

Summary of Contents for Carmanah G Series

  • Page 1 G Series TRAFFIC BEACON QUICK START GUIDE For the SC315-G, R820-G, R829-G, and R247-G flashing beacons 84776_QSG _TRA_G-Series_RevC Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com | carmanah.com...

  • Page 2: Safety Precautions

    This quick start guide is not a replacement for the complete product user manual. Visit carmanah.com to download the complete product user manual. Tools and Materials Required The following tools and materials may be required to mount your Carmanah flashing beacon depending on the G Series model and configuration: a. Imperial socket set h.
  • Page 3 G SERIES QUICK START GUIDE 3.1 Commissioning After installing and programming the G Series flashing beacon system, the following commissioning verification checklist helps ensure that everything is working as it should be and that your system is ready to serve the public for many years of reliable and sustained operation.
  • Page 4 2. For top of pole systems, attach solar panel to top of pole mount using supplied 1/4" bolts, washers and locknuts. Leave nuts finger tight. DO NOT FULLY TIGHTEN at this stage. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com...
  • Page 5 4. Make sure panel mount sits securely on the top of pole cap, as shown below (image shows solar panel removed for illustration purposes). Orient so panel faces South (in Northern Hemisphere). 5. Install and tighten supplied 5/8” bolts and washers. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 6 6. Tighten ¼” bolts and nuts securing solar panel to mount. 7. Route supplied solar panel wires down pole and through hole for cabinet conduit nipple (side of pole shown). Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...

  • Page 7: Cabinet Mounting

    1. Mark the positions of the flashing beacon(s), LED sign(s) or light bar(s) and cabinet on pole. Drill holes for cables and pipe nipple exit/entry points as shown below. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com...
  • Page 8 3. Feed beacon or light bar harness(es) through cabinet pipe nipple. Hole drilled for cabinet pipe nipple Hole drilled for flashing beacon harness Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 9 5. Connect solar panel harness to terminals on right side of cabinet: red wire with yellow heat shrink to Solar (+), black wire with brown heat shrink to Solar (−). Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com...
  • Page 10 White / NEUTRAL to the terminal block and Green / GROUND to the ground bus bar. Ensure cabinet door is fully closed and latched otherwise damage may occur Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com...
  • Page 11 If the pedestrian confirmation light is not required in one direction, use the supplied opaque label to cover the indicator light. Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com...

  • Page 12: Ems Programming And Testing

    G SERIES QUICK START GUIDE Push Button Installation (SC315-G / R820-G) If the G Series is wired for a pushbutton but none is needed (such as an advance RRFB), insulate the ends and secure the wires. The push button can be connected in either polarity.
  • Page 13 G SERIES QUICK START GUIDE Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 14 Allows the system to run a number of self tests and can be used for troubleshooting purposes. Firmware Displays the firmware version programmed on the Version system controller (EMS). Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...

  • Page 15: Troubleshooting

    The EMS is looking for the other fixture in the alternate pattern and declares an “LED Open” fault when it doesn’t find one. Set flash pattern to unison. showing on User Interface Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
  • Page 16 G SERIES QUICK START GUIDE © 2020 Carmanah Technologies Corporation Technical Support: Email: customersupport@carmanah.com Toll Free: 1.877.722.8877 (US & Canada) Worldwide: 1.250.380.0052 Fax: 1.250.380.0062 Web: carmanah.com Carmanah Technologies Corp. | 250 Bay St, Victoria, BC V9A 3K5, Canada | 1.250.380.0052 | customersupport@carmanah.com carmanah.com...
