2. Specifications
Solenoid type
Operating pressure range
Valve
Ambient temperature
specifications
Operating fluid temperature
Vibration/ Impact resistance
Coil
specifications
Allowable leakage voltage
3. Features
This product discharges high peak pressure by discharging the air in the upstream piping at once.
The peak pressure is adjustable depending on the upstream piping condition.
It is effective to increase the upstream piping diameter for higher peak pressure.
(Reference) Piping condition and peak pressure
Upstream piping I.D.
ø8
ø10
ø13
※ In SMC test conditions.
※ Refer to page 5 for the relation between the upstream piping and peak pressure.
※ Oscillation may occur when supply air is insufficient. Upstream piping I.D. Must be larger than ø8.
Be careful that pressure drop does not occur.
Fluid
Rated voltage
Allowable voltage
fluctuation
Length (mm)
Air
0.15 to 0.7 MPa
+5～50℃
150/30 m/s²
24 VDC
+/-10% of the rated
voltage
3% of the rated
voltage or less
Peak pressure (compared
2000
1300
800
2
with existing product)
2 times
2.5 times
3 times
