INSTALLATION CERTIFICATE
The undersigned qualified installer attests having personally fitted the alarm system on the vehicle
specified below, following the manufacturer's instructions
.
By :
973AR
Sold on :
Type of device
:
973
................................................
Vehicle :
INSTALLATION AND USE
..........................................................................................................................
MANUAL
UK
GEMINI Technologies S.p.A.
Via Luigi Galvani 12 - 21020 Bodio Lomnago (VA) - Italia
Tel. +39 0332 943211 - Fax +39 0332 948080
Made in Italy
Web site: www.gemini-alarm.com
AC 2792/UK Rev. 01 - 11/10
Reg. n.532-A
UNI EN ISO 9001:2008
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Gemini 973AR
Summary of Contents for Gemini 973AR
- Page 1 ..........Vehicle : INSTALLATION AND USE .......................... MANUAL GEMINI Technologies S.p.A. Via Luigi Galvani 12 - 21020 Bodio Lomnago (VA) - Italia Tel. +39 0332 943211 - Fax +39 0332 948080 Made in Italy Web site: www.gemini-alarm.com AC 2792/UK Rev. 01 - 11/10 Reg.
- Page 2 1.0 - PRELIMINARY ADVICE TABLE OF CONTENTS Dear customer, - PRELIMINARY ADVICE..................... PAGE 03 The following signs are intended to draw user and installer attention to particular functions or USER MANUAL connections as follows: - OPERATING DESCRIPTION..................PAGE 03 2.1 - Complete system arming..................PAGE 03 Indications useful for the user.
- Page 3 System disarming is confirmed by two beeps of the siren and two flashes of the turn indicators. 2.7 - ALARM MEMORY The 973AR alarm system has an anti-hijack feature for protection against aggression or vehicle theft. If the turn indicators flash 5 times and the siren chirps 5 times upon disarming, the last cause of alarm It operates by means of an automatic transmitter (TAG), which comunicates with the 973AR module can be identified by the LED memory.
- Page 4 INSTALLATION MANUAL 6.0 - COMPLETE ELECTRIC DIAGRAM 5.0 - CONNECTOR TABLE Before carrying out all WIRE COLOR POSITION WIRE FUNCTION electrical connections, disconnect the negative - 1 - Bonnet push-button negative input GREEN battery terminal and re- - 1 - External sensor negative input GREEN -BLACK...
- Page 5 7.0 - SYSTEM PROGRAMMING 8.0 - SYSTEM PROGRAMMING EXAMPLE The t able below applies to the system programmed in “standard configuration”. To better understand the programming procedure, here below is an example of the procedure to follow ntering the programming procedure resets the functions to the default setting to modify the programmable functions.
- Page 6 9.0 - ADDING NEW DEVICES 10.0 - DELETING PROGRAMMED DEVICES To carry out this operation successfully, you must first make the required electrical To carry out this operation successfully, you must first make the required electrical connections (door switch, bonnet switch and positive under key). connections (door switch, bonnet switch and positive under key).
- Page 7 11.0 - ULTRASONIC VOLUMETRIC PROTECTION 13.0 - TAG CARD ACTIVATION AND BATTERY REPLACEMENT To activate the TAG CARD simply press the button and keep it pressed for at least 4 seconds. 11.1 - C ONNECTION AND POSITIONING The LED turns on steady when the TAG is activated and it will flash each time the TAG transmits. Insert the WHITE connector into the port marked “W”...
- Page 8 The warranty will become void if labels are misssing or torn, if the installation certificate is not fully compiled or if the enclosed sale document is missing. The warranty is valid exclusively at Authorized Gemini Centers. The manufactuer declines any responsability for eventual malfunctions of the device or any damage to the vehicle electrical system due to improper installation, use or tampering.
