Avenir
PAB-4 Joining Panels Of The Same Height
(One panel to the join seam of two panels, either side)
ADDED PANELS
JOIN SEAM
ADDED PANELS
1
of
4
3/16" WRENCH
3/8" SOCKET
939500723 Rev A
