Quick Installation Guide
X1 Series 0.7KW-2.0KW

Packing Lists

I
X1
Female DC unit×1
Inverter ×1
Negative DC pin contact ×1
Male DC unit×1
Ring terminal ×1
AC terminal×1
X1 Series 0.7KW-2.0KW
Quick installation guide×1
Warranty card×1
Note:
1) Please refer to the appropriate instruction manual for the usage of optional accessories.
Expansion tube×2
Male DC unit×1
Expansion screw ×2
Female DC unit×1
Positive DC pin contact ×1
X1 Series User Manual
0.7kw - 2.0kw
Copyright Declaration
The copyright of this manual belongs to Solax Power Network Technology(Zhe jiang) Co,. Ltd.
and no reproduction or distribution of it in any form or by any means. All rights reserved. SolaX
Any corporation or individual should not plagiarize, partitially or fully copy (including software,etc.),
Plug and Play Pocket WiFi×1
Power Network Technology (Zhe jiang) Co.,Ltd. reserves the right of final interpretation.
Product manual×1
(optional)

Inverter Installation

II
- Unscrew the bracket from the back of the inverter.
- Mark the position of the two holes.
- Tighten the expansion tubes.
- Screw the expansion screws.
III

PV Connection

Cable size: 12 AWG
trip length:
7.0mm
12 AWG
positive DC
pin contact
negative DC
pin contact
cable
clamp contact
- Drill holes with φ10.
- Depth: at least 50mm.
200mm
- Match the inverter with the bracket.
- Screw the cross recessed screw on the right side.
300mm
300mm
300mm
300mm
300mm
-Align the two halves connectors.
nut
tight nut
male plug
female plug

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SolaX Power X1 Series

  • Page 1 Copyright Declaration The copyright of this manual belongs to Solax Power Network Technology(Zhe jiang) Co,. Ltd. Any corporation or individual should not plagiarize, partitially or fully copy (including software,etc.), and no reproduction or distribution of it in any form or by any means. All rights reserved. SolaX Ring terminal ×1...
  • Page 2 AC Connection Firmware Upgrading outer jacket - Open the communication lid on the bottom of the inverter as below. 52.5mm 1.Slide the cable nut andback shell onto the cable. trip length 2.Insert the tripped end of each threewires into holes in the female 55mm insert, then tighten each screw with L-type wrench.
