Summary of Contents for dallmeier PVS IV
- Page 1 Installation and Configuration PView Station PVS IV English Workstation PVS IV Dallmeier electronic Rev. 1.0.0 / 080528...
- Page 2 All rights reserved. This document may not be copied, photocopied, reproduced, translated, transferred to an electronic medium or converted to a machine-readable form either whole or in part without first receiving written permission from Dallmeier electronic GmbH & Co.KG. We reserve the right to make technical modifications.
-
Page 3: Table Of Contents
PView Station PVS IV Table of contents This document Validity Documents Conventions Safety instructions General notes Scope of delivery Transportation and packaging Appropriate use Performance features Warranty Certifications Installation and mounting Requirements at the installation site Installation in a 19’’ standard rack... -
Page 4: This Document
PView Station PVS IV This document Validity This document applies to the Workstation PVS IV. It has been produced on the basis of the following versions: ® ® ® Microsoft Windows , SP2, incl. all the latest security updates PView: 5.6.4.29d P Guard 4.0.2.13d SP F... - Page 5 PView Station PVS IV IMPORTANT The word IMPORTANT denotes information for preventing damage, incorrect configurations or incorrect actions. NOTE A NOTE offers information on principles, special features and efficient procedure as well as general recommendations. Expression Expressions in bold and italics generally indicate a control element on the device (switches or lables) or on its users interface (buttons, menu, entries).
-
Page 6: Safety Instructions
In order to provide best compatibility and integratability the system is delivered without separate software for protection against malware or data loss. Take appropriate measures for malware protection. Regularly make backups to avoid data loss. Dallmeier electronic accepts no liability for damage caused by insufficient system security. - Page 7 Furthermore, the use of peripheral devices that are not certified by Dallmeier electronic results in loss of warranty. In case of doubt, contact the sales partner responsible for your area.
-
Page 8: General Notes
Transportation and packaging Store the original packaging for transportation at a later date. Dallmeier electronic is not responsible for damage resulting from unprofessional/improper transportation. The goods should only be shipped in their original packaging. -
Page 9: Appropriate Use
(DIS, DLS, DMS, DVS). Its powerful CPU enables a smooth video display with high image quality in up to 6 independent splits. The connection between PVS IV and one or more Dallmeier recorders is realised via an IP based network (ISDN optional). All necessary hardware and software is already installed and pre-configured. -
Page 10: Installation And Mounting
PView Station PVS IV Installation and mounting The PVS IV is designed for stand-alone operation. As an option it may also be installed in a 19’’ standard rack. Requirements at the installation site Unfavorable local conditions may shorten the life of the product or lead to malfunctions. -
Page 11: Installation In A 19'' Standard Rack
PView Station PVS IV Installation in a 19’’ standard rack The PVS IV can be installed in a 19’’ standard rack using a 19’’ bracket (optional). 1 Place the PVS IV into the bracket. 2 Pay attention to the case feet that must fit into the notches (A). -
Page 12: Views And Connection Assignment
PView Station PVS IV Views and connection assignment Front view Fig. 5-1 1 Panel / Filter pad 2 Power LED Lights whenever the device is switched on. 3 Status LEDs (inactive) 4 USB 2.0 interface 5 Panel / DVD drive... -
Page 13: Connection Assignment
3 Serial interface (9-pin D-SUB, RS232) 4 Parallel interface (25-pin D-SUB) 5 M3, VGA output (15-pin D-SUB), inactive This output will be activated as M1 in case of a PVS IV version without additional VGA card. 6 2 x RJ45 (inactive) 7 2 x USB 2.0... -
Page 14: Connection And Commissioning
The main board’s DVI output (12) is not suitable for a VGA adapter. Commissioning Ø Switch on the periphal devices, if necessary. Ø Connect the supplied dongle to a USB port on the PVS IV. Ø Connect the power supply. Ø Switch on the PVS IV. Dallmeier electronic... - Page 15 Automatic start from the software PView and PGuard. NOTE A dialog requesting to enter the serial number will be displayed when the Dallmeier software is starting if the licence dongle is not connected accurately. If the dialog to enter the serial number is displayed, proceed as follows: Ø Close the dialog Hardlock-Dongle unlocking with Cancel.
-
Page 16: Configuration
PView Station PVS IV Configuration Periphery Peripheral devices (printer, keyboard, etc.) have to be connected and installed with the current drivers according to the manufactures guidelines. NOTE Note the documentation of the operating system and peripheral devices. Monitors Ø Open the desktop context menu by right-clicking on the desktop. -
Page 17: Software
To configure other monitors proceed analog as above. Fig. 7-2 Software The PView, PGuard and SmartGUI software is already installed on the PVS IV. It finally has to be configured for the particular application. NOTE Please refer to the according manuals for detailed information on the installed software (PView, PGuard etc.). -
Page 18: Maintenance
PView Station PVS IV Maintenance Changing the filter mat and possibly occasional cleaning of the housing are the only main- tenance work that you have to carry out at your system. 8.1 Changing the filter mat A filter mat is positioned behind the front panel in front of the intake fan. This filter mat pre- vents dirt particles in the ambient air from entering the unit. -
Page 19: Appendix
PView Station PVS IV Appendix Technical data ® ® Intel Pentium M 1.8 GHz ® Chip set Intel GME 855 ® Graphics card (main board) Intel GME 855 Graphics card Matrox P690 PCIe (optional) Memory (main board) Min. 1 GB... -
Page 20: Technichal Drawing
PView Station PVS IV Technichal drawing Fig. 9-1 Unit: mm Dallmeier electronic... - Page 21 PView Station PVS IV Declaration of Conformity This declaration is valid for the following product: Equipment: Workstation Type: PVS IV Hereby the equipment is confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compability 89/336/EEC and the Council Directive relating to Low Voltage 73/23/EEC.
