ARB WINCH BULL BAR TO SUIT
SUZUKI SIERRA WITH 5 OR 6,000lb WINCH
THIS BULL BAR MUST NOT BE FITTED TO AIRBAG EQUIPPED VEHICLES.
FITMENT TO AIRBAG EQUIPPED VEHICLES MAY INTERFERE WITH THE
PROPER OPERATION OF THE AIRBAGS AND MAY RESULT IN SERIOUS INJURY.
TAKE NOTE OF THE FOLLOWING:
• THIS PRODUCT MUST BE INSTALLED EXACTLY AS PER THESE INSTRUCTIONS USING ONLY THE
HARDWARE SUPPLIED.
• IN THE EVENT OF DAMAGE TO ANY BULL BAR COMPONENT, CONTACT YOUR NEAREST
AUTHORISED ARB STOCKIST. REPAIRS OR MODIFICATIONS TO THE IMPACT ABSORPTION SYSTEM
MUST NOT BE ATTEMPED.
• DO NOT USE THIS PRODUCT FOR ANY VEHICLE MAKE OR MODEL, OTHER THAN THOSE SPECIFIED
BY ARB.
• DO NOT REMOVE LABELS FROM THIS BULL BAR.
• THIS PRODUCT OR IT'S FIXING MUST NOT BE MODIFIED IN ANY WAY.
BULL BAR FITTING KIT No 6171072
PART No
QTY
6151077
3/8 X 2 ¾" BOLT
4
6151071
2
3/8 X 1" BOLT
6151123
6
3/8" NUT
4581040
3/8" FLAT WASHER
12
4581048
6
M10 SPRING WASHER
4581072
3
¼" FLAT WASHER
5811005
2
CHASSIS SLEEVE LONG (43mm)
5811006
CHASSIS SLEEVE SHORT (38mm)
2
3751485
1
NUMBER PLATE BRACKET
6151180
4
M6x20mm BOLTS
6151128
M6 FLANGE NUTS
4
6151046
4
M6 FLAT WASHERS
1212174
4
SPEED NUTS
PT003-12B
RUBBER CAP FOR SCREWS
4
02/08/2009
If you have any queries regarding the installation of this product please contact the distributor from whom it was purchased, or alternatively the ARB office in your state.
Head Office – ARB Corporation Ltd VIC: 42-44 Garden Street, Kilsyth, Victoria, 3137 Tel: (03) 9761 6622 Fax: (03) 9761 6807
WA: (08) 9244 3553 NSW: (02) 9821 3633 ACT: (02) 6280 7475 SA: (08) 8244 5001 QLD: (07) 3872 3872 NT: (08) 8947 2262 TAS: (03) 6331 4190
WARNING
DESCRIPTION
Page 1 of 3
OPTIONALWINCH MOUNT KIT No 3524010
PART No
QTY
6151251
BOLT M16 X 2.0 X 150
2
4581051
5/8" FLAT WASHER
4
6151252
2
NYLOC NUT M16 X 2.0
4581048
6
BOLT UNC 3/8" X 1 ¾"
180302
CABLE TIE
4
BLB1100
2
BATTERY LEAD
BLR1100
1
BATTERY LEAD
3757857
BRACKET RFL BOLT ON
1
No 3424010/110
DESCRIPTION
3782574
Advertisement
Related Manuals for ARB 3424010
Summary of Contents for ARB 3424010
- Page 1 3782574 If you have any queries regarding the installation of this product please contact the distributor from whom it was purchased, or alternatively the ARB office in your state. Head Office – ARB Corporation Ltd VIC: 42-44 Garden Street, Kilsyth, Victoria, 3137 Tel: (03) 9761 6622 Fax: (03) 9761 6807...
- Page 2 9. Mount the winch into the rear of the bull bar. Visually locate the top holes and secure the winch using the 3/8” x 1 1/4” bolts (from the Warn winch bolt kit) and four M10 (3/8”) flat washers from the ARB fitting kit.
- Page 3 FITTING THE BULL BAR TO THE VEHICLE 10. Remove indicator assemblies from the existing bumper bar. 11. Remove the number plate and bumper from vehicle. Place aside the number plate and fasteners. 12. Fit the four sleeve inserts into the chassis rails. NOTE: The longer sleeves (43mm) fit above the shorter (38mm) sleeves.
