ARB WINCH BULL BAR TO SUIT PAJERO GLS 1997 ON
WHEN INSTALLED IN ACCORDANCE WITH THESE INSTRUCTIONS, THE FRONT
PROTECTION BAR DOES NOT AFFECT OPERATION OF THE SRS AIRBAG.
TAKE NOTE OF THE FOLLOWING:
• THIS PRODUCT MUST BE INSTALLED EXACTLY AS PER THESE INSTRUCTIONS USING ONLY THE
HARDWARE SUPPLIED.
• DO NOT USE THIS PRODUCT FOR ANY VEHICLE MAKE OR MODEL, OTHER THAN THOSE SPECIFIED
BY ARB.
• DO NOT REMOVE LABELS FROM THIS BULL BAR.
• THIS PRODUCT OR ITS FIXING MUST NOT BE MODIFIED IN ANY WAY.
FITTING KIT No 6171268
USE
CONTROL BOX BRKT
TO B/BAR
B/BAR TO CHASSIS
No PLATE BRACKET AND
NUMBER PLATE
ROLLER FAIRLEAD TO
B/BAR
WINCH TO B/BAR
INDICATORS TO B/BAR
13-1-99
If you have any queries regarding the installation of this product please contact the distributor from whom it was purchased, or alternatively the ARB office in your state.
Head Office – ARB Corporation Ltd VIC: 42-44 Garden Street, Kilsyth, Victoria, 3137 Tel: (03) 9761 6622 Fax: (03) 9761 6807
WA:(08) 9244 3553 NSW: (02) 9821 3633 ACT: (02) 6280 7475 SA: (08) 8244 5001 QLD: (07) 3872 3872 NT: (08) 8947 2262 TAS: (03) 6331 4190
WARNING
FOR VEHICLES EQUIPPED WITH SRS AIRBAG
PART No
QTY
3751357
1
6151021
2
6151132
2
4581044
2
4581049
10
4581050
6
6151100
2
6151138
6
6151104
4
4581013
2
4581007
4
3751584
1
6151017
4
4581035
4
6151128
4
6151110
2
6151140
2
4581051
4
6151073
4
4581048
4
4581040
4
6821110
1
3500080
1
Page 1 of 4
DESCRIPTION
CONTROL BOX BRACKET
BOLT M8 X 20mm
NUT FLANGE M8
WASHER FLAT M8
WASHER FLAT ½"
WASHER SPRING ½"
BOLT ½" X 1½"
NUT ½"
BOLT ½" X 4"
WASHER LOCATING
WASHER FLAT HD 13mm X 40mm
NUMBER PLATE BRACKET
BOLT M6 X 16mm
WASHER FLAT M6
NUT FLANGE M6
BOLT 5/8" X 6"
NUT 5/8" NYLOC
WASHER FLAT 5/8"
BOLT UNC 3/8" X 1½"
SPRING WASHER 3/8
WASHER FLAT 3/8" X 1"
RUBBER GROMMET 56mm DIA
ARB INDICATOR KIT
No 3434040
3782557
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ARB 3434040
Summary of Contents for ARB 3434040
- Page 1 3782557 If you have any queries regarding the installation of this product please contact the distributor from whom it was purchased, or alternatively the ARB office in your state. Head Office – ARB Corporation Ltd VIC: 42-44 Garden Street, Kilsyth, Victoria, 3137 Tel: (03) 9761 6622 Fax: (03) 9761 6807...
- Page 2 TOOLS REQUIRED Basic tool kit, drill and ½” drill bit PROCEDURE Place the bull bar onto a suitable stand. Mount the control box to the control box bracket using the original nuts from the control box. Assemble the number plate bracket to the bull bar using two M6.x 16mm bolts, flat washers and flange nuts.
- Page 3 Place the bull bar on top of the winch and align with the mounting holes. Using the bolts supplied with the winch and the 3/8” washers in the ARB kit, fit and tighten the two upper bolts. Place the roller fairlead in position over the two lower holes and fit two 3/8” x 1 ¾” bolts and 3/8”...
- Page 4 Slide the 38mm x 4mm washer between the chassis and the bull bar mounting bracket. Position the locating washer into the chassis eye. Refer to the diagram below for the correct bolt assembly. Tighten all bolts making sure the bull bar is correctly aligned with the vehicle. 23.
