Statement of Shuttle Mainboard via the EMI Test
Shuttle mainboards have been via the EMI test in terms of series of regulations: EN55022/
CISPR22/AS/NZS3548 Class B, EN55024 (1998/AS/NZS), EN4252.1 (1994), EN61000, ANSI
C63.4 (1992), CFR47 Part 15 Subpart B, and CNS13438 (1997). The items tested are illus-
trated as follows:
(A) Voltage: AC 110V/60HZ & AC 230V/50HZ
(B) Tested Product Information:
Product Name: PC Mainboard
Status: Sample
Model Name: MS52PN
S/N:
CPU:
External Frequency: 100 MHz
Intel P4 1.4/1.5/1.6/1.7/1.8/1.9/2/2.2/2.4 GHz
External Frequency: 133 MHz
Intel P4 1.6/1.7/2.26/2.4/2.8/3.06 GHz
Keyboard Port: one port with 6 pins
Mouse Port: one port with 6 pins
USB 2.0 Port: two ports with 4 pins respectively
Parallel Port: one port with 9 pins
Serial Port: two ports with 9 pins respectively
MIDI/Game Port: one port with 15 pins
Line-Out & Line-In & Mic-In Ports: one port for each
DDR Memory: 256 MB *2
LAN Port: one port with 8 pins
All CPUs have completely been tested, and values offered by the worst EMI combination of
CPU external frequency are listed as follows:
Test Mode External Frequency
1 133MHz
2 133MHz
3 100MHz
4 100MHz
(C) Remedy for the Tested Product & Its EMI Interference:
Remedy: N/A
EMI Interference:
Crystal: 14.318 KHz(Y1)/24.576 MHz(Y2)/32.768 MHz(Y3)/25MHz(Y4)/12MHz(Y5)
Clock Generator: CLK1/CLK2
C P U Case Open/C losed
Pentium4
C losed
3.06GHz
Pentium4
Open
3.06GHz
Pentium4
C losed
2.4GHz
Pentium4
Open
2.4GHz
