- Form Factor
System board conforms to Micro ATX specification.
Board dimension: 244mm x244mm.
- Advanced Features
Ø Low EMI - Built in spread spectrum and automatic clock shut-off of
unused PCI/SDRAMS slots to reduce EMI.
Ø Dual Function Power Button - The system can be in one of two states,
one is Suspend mode and the other is Soft-Off mode. Pushing the power
button for less than 4 seconds places the system into Suspend mode.
When the power button is pressed for longer than 4 seconds, the system
enters Soft-Off mode.
Ø Modem Ring Power-On (WOM1) - The system can be powered on
automatically by the activation of modem ringing.
Ø Wake-on-Lan (WOL1) - The onboard WOL connector can be attached to
a network card that supports this function to wake up the system via LAN.
Ø CPU Host/DRAM/PCI Clock Setting - This item allows users to adjust
CPU Host Clock, DRAM, and PCI Clock in BIOS.
Ø CPU Multiplier Setting - This item allows users to adjust CPU Multiplier
in BIOS.
- Intelligent Features
Ø Voltage Monitoring - Monitors various voltages of key elements, such as
the CPU, and other critical system voltage levels to ensure stable current
passing through mainboard components.
Ø Fan Status Monitoring - To prevent CPU from overheating, the CPU fan
is monitored for RPM (CPU Cooling FAN with RPM sensor is required.)
Ø Temperature Monitoring - This item allows users to make sure whether
the CPU or system runs in a suitable temperature.
