mundoclima MAXI MVD V6X Engineering Data Book page 62

Table 2-8.2: 10HP cooling capacity (continued)
Combination
Outdoor
(%)
temperature
(Capacity
(°C DB)
index)
-5
-2
0
2
4
6
8
10
12
14
16
18
20
50% 21
23
25
27
29
31
33
35
37
39
41
43
45
48
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes:
Shaded cells indicate rating condition.
DB:20.8,WB:14 DB:23.3,WB:16
TC PI TC PI
kW kW kW kW
9.5 1.09 11.3 1.26
9.5 1.10 11.3 1.29
9.5 1.12 11.3 1.31
9.5 1.13 11.3 1.33
9.5 1.15 11.3 1.35
9.5 1.17 11.3 1.37
9.5 1.19 11.3 1.39
9.5 1.22 11.3 1.41
9.5 1.23 11.3 1.43
9.5 1.25 11.3 1.45
9.5 1.26 11.3 1.46
9.5 1.28 11.3 1.49
9.5 1.30 11.3 1.51
9.5 1.31 11.3 1.53
9.5 1.33 11.3 1.55
9.5 1.35 11.3 1.57
9.5 1.37 11.3 1.64
9.5 1.45 11.3 1.73
9.5 1.53 11.3 1.83
9.5 1.62 11.3 1.94
9.5 1.71 11.3 2.05
9.5 1.80 11.3 2.16
9.5 1.90 11.3 2.28
9.5 1.98 11.3 2.38
9.5 2.11 11.3 2.55
9.5 2.16 11.3 2.61
9.5 2.20 11.3 2.67
Indoor temperature(°C DB/WB)
DB:25.8,WB:18 DB:27,WB:19
TC PI TC PI
kW kW kW kW
13.1 1.45 14.0 1.52
13.1 1.47 14.0 1.54
13.1 1.49 14.0 1.56
13.1 1.52 14.0 1.58
13.1 1.54 14.0 1.60
13.1 1.56 14.0 1.64
13.1 1.59 14.0 1.68
13.1 1.61 14.0 1.70
13.1 1.64 14.0 1.74
13.1 1.66 14.0 1.77
13.1 1.68 14.0 1.80
13.1 1.71 14.0 1.83
13.1 1.74 14.0 1.86
13.1 1.76 14.0 1.87
13.1 1.78 14.0 1.91
13.1 1.82 14.0 1.95
13.1 1.92 14.0 2.07
13.1 2.04 14.0 2.20
13.1 2.16 14.0 2.34
13.1 2.29 14.0 2.47
13.1 2.42 14.0 2.62
13.1 2.57 14.0 2.77
13.1 2.71 14.0 2.94
13.1 2.81 14.0 3.08
13.1 2.91 14.0 3.21
13.1 3.10 14.0 3.46
13.1 3.27 14.0 3.69
DB:28.2,WB:20 DB:30.7,WB:22
TC PI TC PI
kW kW kW kW
14.9 1.60 16.7 1.82
14.9 1.63 16.7 1.85
14.9 1.65 16.7 1.88
14.9 1.68 16.7 1.89
14.9 1.71 16.7 1.93
14.9 1.74 16.7 1.96
14.9 1.77 16.7 1.99
14.9 1.82 16.7 2.05
14.9 1.86 16.7 2.08
14.9 1.88 16.7 2.12
14.9 1.91 16.7 2.16
14.9 1.95 16.7 2.19
14.9 1.98 16.7 2.23
14.9 2.00 16.7 2.26
14.9 2.04 16.7 2.29
14.9 2.10 16.7 2.41
14.9 2.23 16.7 2.57
14.9 2.37 16.7 2.73
14.9 2.52 16.7 2.90
14.9 2.67 16.7 3.08
14.9 2.83 16.7 3.27
14.9 3.00 16.7 3.47
14.9 3.18 16.7 3.68
14.9 3.32 16.7 3.88
14.9 3.41 16.7 4.08
14.9 3.55 16.7 4.47
14.9 3.72 16.7 4.82
DB:32,WB:24
TC PI
kW kW
18.6 1.96
18.6 1.99
18.6 2.03
18.6 2.06
18.6 2.12
18.6 2.18
18.6 2.25
18.6 2.28
18.6 2.32
18.6 2.37
18.6 2.40
18.6 2.45
18.6 2.49
18.6 2.52
18.6 2.57
18.6 2.75
18.6 2.93
18.6 3.12
18.6 3.32
18.6 3.53
18.6 3.75
18.6 3.98
18.6 4.23
18.6 4.43
18.6 4.62
18.6 5.02
18.6 5.40
