mundoclima MAXI MVD V6X Engineering Data Book page 201

Table 2-8.49: 24HP heating part load performance
Outdoor air temp.
Part load
°C DB °C WB
-25 -25.4
-19.8 -20
-18.8 -19
-16.7 -17
-13.7 -15
-11.8 -13
-9.8 -11
-9.5 -10
-8.5 -9.1
-7 -7.6
100%
-5 -5.6
-3 -3.7
0 -0.7
3 2.2
5 4.1
7 6
9 7.9
11 9.8
13 11.8
15 13.7
-25 -25.4
-19.8 -20
-18.8 -19
-16.7 -17
-13.7 -15
-11.8 -13
-9.8 -11
-9.5 -10
-8.5 -9.1
-7 -7.6
75%
-5 -5.6
-3 -3.7
0 -0.7
3 2.2
5 4.1
7 6
9 7.9
11 9.8
13 11.8
15 13.7
Abbreviations:
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
200
16 18
TC PI TC PI
kW kW kW kW
52.44 18.22 52.23 18.40
54.88 18.22 54.66 18.42
55.73 18.26 55.51 18.46
56.58 18.28 56.37 18.48
57.43 18.33 57.22 18.51
58.28 18.35 58.07 18.55
58.70 18.37 58.70 18.57
59.13 18.40 58.92 18.57
59.77 18.42 59.77 18.60
64.45 18.44 64.23 18.60
65.30 18.46 65.09 18.61
66.57 18.48 66.36 18.63
68.28 18.51 72.10 18.64
72.74 18.14 72.10 18.17
77.21 17.85 72.10 17.29
77.21 17.63 72.10 16.40
77.21 16.62 72.10 15.53
77.21 15.55 72.10 14.57
77.21 14.57 72.10 14.21
77.21 13.86 72.10 13.61
57.31 17.51 53.90 16.20
57.31 16.68 53.90 15.34
57.77 16.50 53.90 15.18
57.77 16.16 53.90 14.88
57.77 15.84 53.90 14.58
57.77 15.52 53.90 14.30
57.77 15.22 53.90 14.03
57.77 15.08 53.90 13.91
57.77 14.94 53.90 13.79
57.77 14.74 53.90 13.59
57.77 14.28 53.90 13.19
57.77 13.52 53.90 12.79
57.77 12.80 53.90 12.23
57.77 12.08 53.90 11.56
57.77 11.53 53.90 10.83
57.77 11.08 53.90 10.36
57.77 10.60 53.90 9.96
57.77 10.18 53.90 9.62
57.77 9.80 53.90 9.23
57.77 9.45 53.90 8.81
Indoor air temp. °C DB
20 21
TC PI TC PI
kW kW kW kW
52.02 18.50 52.02 18.71
54.45 18.62 54.45 18.73
55.30 18.66 55.30 18.75
56.37 18.68 56.15 18.80
57.22 18.73 57.00 18.82
58.07 18.75 57.85 18.86
58.49 18.77 58.49 18.86
58.92 18.82 58.70 18.88
59.56 18.88 59.34 18.91
64.23 19.26 64.02 19.60
65.09 18.81 64.45 19.04
66.36 18.20 64.45 17.94
67.00 17.69 64.45 17.13
67.00 17.18 64.45 16.29
67.00 16.37 64.45 15.56
67.00 15.33 64.45 14.73
67.00 14.90 64.45 14.37
67.00 14.41 64.45 13.79
67.00 13.85 64.45 13.30
67.00 13.34 64.45 12.83
50.26 15.92 48.21 15.63
50.26 15.03 48.21 14.74
50.26 14.87 48.21 14.58
50.26 14.61 48.21 14.32
50.26 14.33 48.21 14.04
50.26 14.10 48.21 13.81
50.26 13.84 48.21 13.55
50.26 13.49 48.21 13.20
50.26 13.04 48.21 12.75
50.26 12.47 48.21 12.18
50.26 12.13 48.21 11.84
50.26 11.78 48.21 11.49
50.26 11.28 48.21 10.99
50.26 10.59 48.21 10.30
50.26 10.19 48.21 9.90
50.26 9.66 48.21 9.40
50.26 9.34 48.21 9.05
50.26 8.97 48.21 8.68
50.26 8.54 48.21 8.25
50.26 8.20 48.21 7.91
22 24
TC PI TC PI
kW kW kW kW
52.02 18.82 51.80 19.06
54.45 18.84 54.24 18.93
55.30 18.86 55.09 18.78
56.15 18.91 55.94 18.68
57.00 18.93 56.79 18.46
57.85 18.95 56.79 18.26
58.28 18.97 56.79 18.23
58.70 19.00 56.79 18.08
59.34 19.02 56.79 17.80
61.90 18.64 56.79 17.74
61.90 18.08 56.79 17.24
61.90 17.51 56.79 16.67
61.90 16.65 56.79 15.94
61.90 15.66 56.79 15.16
61.90 15.02 56.79 14.49
61.90 14.41 56.79 13.85
61.90 13.99 56.79 13.40
61.90 13.47 56.79 12.84
61.90 13.00 56.79 12.40
61.90 12.53 56.79 11.92
46.39 15.43 42.53 14.86
46.39 14.55 42.53 13.97
46.39 14.39 42.53 13.81
46.39 14.13 42.53 13.55
46.39 13.85 42.53 13.27
46.39 13.61 42.53 13.03
46.39 13.35 42.53 12.77
46.39 13.00 42.53 12.42
46.39 12.55 42.53 11.97
46.39 11.99 42.53 11.41
46.39 11.65 42.53 11.07
46.39 11.29 42.53 10.72
46.39 10.79 42.53 10.21
46.39 10.11 42.53 9.53
46.39 9.71 42.53 9.13
46.39 9.21 42.53 8.63
46.39 8.86 42.53 8.28
46.39 8.48 42.53 7.91
46.39 8.05 42.53 7.47
46.39 7.72 42.53 7.14
Table continued on next page ...
