mundoclima MAXI MVD V6X Engineering Data Book page 144

Table 2-8.22: 24HP heating capacity (continued)
Outdoor air temp.
CR
°C DB °C WB
-25 -25.4
-19.8 -20
-18.8 -19
-16.7 -17
-13.7 -15
-11.8 -13
-9.8 -11
-9.5 -10
-8.5 -9.1
-7 -7.6
70%
-5 -5.6
-3 -3.7
0 -0.7
3 2.2
5 4.1
7 6
9 7.9
11 9.8
13 11.8
15 13.7
-25 -25.4
-19.8 -20
-18.8 -19
-16.7 -17
-13.7 -15
-11.8 -13
-9.8 -11
-9.5 -10
-8.5 -9.1
-7 -7.6
60%
-5 -5.6
-3 -3.7
0 -0.7
3 2.2
5 4.1
7 6
9 7.9
11 9.8
13 11.8
15 13.7
-25 -25.4
-19.8 -20
-18.8 -19
-16.7 -17
-13.7 -15
-11.8 -13
-9.8 -11
-9.5 -10
-8.5 -9.1
-7 -7.6
50%
-5 -5.6
-3 -3.7
0 -0.7
3 2.2
5 4.1
7 6
9 7.9
11 9.8
13 11.8
15 13.7
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes: Shaded cells indicate rating condition.
16 18
TC PI TC
kW kW kW kW
53.60 19.53 50.41 18.06
53.60 18.60 50.41 17.11
54.03 18.40 50.41 16.93
54.03 18.02 50.41 16.60
54.03 17.66 50.41 16.26
54.03 17.31 50.41 15.95
54.03 16.97 50.41 15.64
54.03 16.82 50.41 15.51
54.03 16.66 50.41 15.37
54.03 16.44 50.41 15.15
54.03 15.93 50.41 14.71
54.03 15.07 50.41 14.26
54.03 14.27 50.41 13.64
54.03 13.47 50.41 12.90
54.03 12.85 50.41 12.07
54.03 12.35 50.41 11.55
54.03 11.82 50.41 11.11
54.03 11.35 50.41 10.73
54.03 10.93 50.41 10.29
54.03 10.53 50.41 9.83
46.37 18.20 43.39 17.21
46.37 17.24 43.39 16.42
46.37 16.80 43.39 15.85
46.37 16.27 43.39 15.36
46.37 15.71 43.39 14.90
46.37 15.15 43.39 14.35
46.37 14.66 43.39 13.82
46.37 14.14 43.39 13.26
46.37 13.55 43.39 12.79
46.37 13.05 43.39 12.24
46.37 12.56 43.39 11.79
46.37 12.12 43.39 11.32
46.37 11.64 43.39 10.87
46.37 11.11 43.39 10.35
46.37 10.54 43.39 9.91
46.37 10.06 43.39 9.49
46.37 9.88 43.39 9.28
46.37 9.74 43.39 9.14
46.37 9.43 43.39 8.84
46.37 9.32 43.39 8.66
38.71 15.07 36.16 14.25
38.71 14.27 36.16 13.59
38.71 13.91 36.16 13.12
38.71 13.47 36.16 12.72
38.71 13.00 36.16 12.34
38.71 12.54 36.16 11.88
38.71 12.14 36.16 11.44
38.71 11.70 36.16 10.98
38.71 11.22 36.16 10.59
38.71 10.80 36.16 10.13
38.71 10.40 36.16 9.76
38.71 10.04 36.16 9.37
38.71 9.64 36.16 9.00
38.71 9.19 36.16 8.57
38.71 8.73 36.16 8.20
38.71 8.33 36.16 7.86
38.71 8.18 36.16 7.68
38.71 8.06 36.16 7.57
38.71 7.81 36.16 7.31
38.71 7.72 36.16 7.17
Indoor air temp. °C DB
20
PI TC PI TC
kW kW kW
47.01 17.75 45.09
47.01 16.76 45.09
47.01 16.59 45.09
47.01 16.30 45.09
47.01 15.99 45.09
47.01 15.72 45.09
47.01 15.43 45.09
47.01 15.04 45.09
47.01 14.54 45.09
47.01 13.91 45.09
47.01 13.53 45.09
47.01 13.13 45.09
47.01 12.58 45.09
47.01 11.81 45.09
47.01 11.36 45.09
47.01 10.78 45.09
47.01 10.42 45.09
47.01 10.00 45.09
47.01 9.52 45.09
47.01 9.15 45.09
40.20 16.41 38.71
40.20 15.79 38.71
40.20 15.23 38.71
40.20 14.76 38.71
40.20 14.30 38.71
40.20 13.75 38.71
40.20 13.09 38.71
40.20 12.56 38.71
40.20 12.03 38.71
40.20 11.62 38.71
40.20 11.04 38.71
40.20 10.54 38.71
40.20 10.07 38.71
40.20 9.69 38.71
40.20 9.33 38.71
40.20 8.89 38.71
40.20 8.76 38.71
40.20 8.53 38.71
40.20 8.26 38.71
40.20 8.02 38.71
33.61 13.59 32.12
33.61 13.07 32.12
33.61 12.61 32.12
33.61 12.22 32.12
33.61 11.84 32.12
33.61 11.38 32.12
33.61 10.84 32.12
33.61 10.40 32.12
33.61 9.96 32.12
33.61 9.62 32.12
33.61 9.14 32.12
33.61 8.73 32.12
33.61 8.34 32.12
33.61 8.02 32.12
33.61 7.72 32.12
33.61 7.36 32.12
33.61 7.25 32.12
33.61 7.06 32.12
33.61 6.84 32.12
33.61 6.64 32.12
21 22
PI TC PI
kW kW kW
17.43 43.39 17.21
16.44 43.39 16.22
16.26 43.39 16.05
15.97 43.39 15.76
15.66 43.39 15.45
15.40 43.39 15.18
15.11 43.39 14.89
14.72 43.39 14.50
14.22 43.39 14.00
13.58 43.39 13.37
13.21 43.39 12.99
12.81 43.39 12.60
12.25 43.39 12.04
11.49 43.39 11.27
11.04 43.39 10.83
10.48 43.39 10.27
10.10 43.39 9.88
9.68 43.39 9.46
9.20 43.39 8.98
8.82 43.39 8.61
16.04 37.01 15.37
15.34 37.01 14.65
14.83 37.01 14.08
14.25 37.01 13.55
13.72 37.01 13.02
13.25 37.01 12.46
12.65 37.01 11.94
12.10 37.01 11.41
11.59 37.01 10.88
11.20 37.01 10.46
10.73 37.01 10.04
10.30 37.01 9.60
9.80 37.01 9.12
9.40 37.01 8.65
8.98 37.01 8.46
8.62 37.01 8.41
8.42 37.01 8.06
8.22 37.01 7.89
8.04 37.01 7.73
7.85 37.01 7.53
13.28 30.84 12.94
12.70 30.84 12.35
12.27 30.84 11.87
11.80 30.84 11.44
11.36 30.84 11.00
10.97 30.84 10.54
10.47 30.84 10.10
10.02 30.84 9.67
9.59 30.84 9.23
9.27 30.84 8.88
8.88 30.84 8.53
8.53 30.84 8.17
8.12 30.84 7.77
7.79 30.84 7.38
7.44 30.84 7.22
7.14 30.84 7.11
6.97 30.84 6.82
6.80 30.84 6.69
6.65 30.84 6.54
6.50 30.84 6.37
24
TC PI
kW kW
39.77 16.57
39.77 15.58
39.77 15.40
39.77 15.11
39.77 14.80
39.77 14.53
39.77 14.24
39.77 13.86
39.77 13.35
39.77 12.72
39.77 12.35
39.77 11.95
39.77 11.39
39.77 10.62
39.77 10.18
39.77 9.62
39.77 9.23
39.77 8.82
39.77 8.33
39.77 7.96
34.03 14.57
34.03 13.81
34.03 13.32
34.03 12.79
34.03 12.26
34.03 11.71
34.03 11.28
34.03 10.66
34.03 10.06
34.03 9.62
34.03 9.16
34.03 8.84
34.03 8.67
34.03 8.35
34.03 8.18
34.03 8.02
34.03 7.67
34.03 7.52
34.03 7.35
34.03 7.15
28.29 12.06
28.29 11.44
28.29 11.03
28.29 10.59
28.29 10.15
28.29 9.69
28.29 9.34
28.29 8.83
28.29 8.32
28.29 7.96
28.29 7.58
28.29 7.32
28.29 7.18
28.29 7.14
28.29 7.06
28.29 6.86
28.29 6.64
28.29 6.52
28.29 6.38
28.29 6.21
143
