mundoclima MAXI MVD V6X Engineering Data Book page 25

58-64HP
Table 2-1.7: 58-64HP specifications
HP
Model name (Combination unit)
Combination type
Power supply
Capacity
1
Cooling
Power input
EER
Capacity
2
Heating (rated)
Power input
COP
Capacity
2
Heating (max)
Power input
COP
Connected Total capacity
indoor unit
Maximum quantity
Type
Quantity
Compressor
Oil type
Start-up method
Type
Motor type
Quantity
Motor output
Fan
Static pressure
Airflow rate
Drive type
Type
Refrigerant
Factory charge
Pipe Liquid pipe
3
connections Gas pipe
4
Sound pressure level
Sound power level
Net dimensions (W×H×D)
Packed dimensions (W×H×D)
Net weight
Gross weight
Cooling
Ambient temp.
operation range
Heating
Notes:
1. Indoor air temperature 27°C DB, 19°C WB; outdoor air temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.
2. Indoor air temperature 20°C DB; outdoor air temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.
3. Diameters given are those for the pipe connecting the outdoor unit combination to the first indoor branch joint for systems with total equivalent liquid
piping lengths of less than 90m. For systems with total equivalent liquid piping lengths of 90m or longer, please refer to Part 3 "System Design and
Installation" for connection piping diameters..
4. Sound pressure level is measured at a position 1m in front of the unit and 1.3m above the floor in a semi-anechoic chamber.
24
58
MVD-V6X1635
W/V2GN1
28HP+30HP
V/Ph/Hz
kW 163.5
kBtu/h 557.9
kW 51.6
3.17
kW 163.5
kBtu/h 557.9
kW 44.1
3.70
kW 182.5
kBtu/h 622.7
kW 53.82
3.39
kW 0.92×4
Pa
3
m /h 49000
kg 22+25
mm
mm
dB(A)
dB(A)
mm
mm
kg 430+475
kg 453+507
o
C
o
C
60
MVD-V6X1685 MVD-V6X1750
W/V2GN1 W/V2GN1
28HP+32HP 30HP+32HP
380-415/3/50
168.5 175.0
574.9 597.1
55.2 58.5
3.05 2.99
168.5 175.0
574.9 597.1
46.9 48.7
3.59 3.59
187.5 195.0
639.8 665.3
56.72 58.45
3.31 3.34
50-130% of outdoor unit capacity
64
DC inverter
4
FV68H
Soft start
Propeller
DC
4
0.92×4 0.92×4
0-20 (default); 20-60 (customized)
49000 48000
Direct
R410A
22+25 25+25
Φ19.1
Φ41.3
70
92
(1730×1830×850)×2
(1800×2000×910)×2
-5 ~ 48
-25 ~ 24
62 64
MVD-V6X1800
W/V2GN1
32HP+32HP
180.0
614.2
62.1
2.90
180.0
614.2
51.4
3.50
200.0
682.4
61.35
3.26
0.92×4
48000
25×2
475×2
507×2
