mundoclima MAXI MVD V6X Engineering Data Book page 177

Table 2-8.37: 26HP cooling part load performance
Outdoor
Part load temperature (°C
DB)
-5
-2
0
2
4
6
8
10
12
14
16
18
20
100%
21
23
25
27
29
31
33
35
37
39
41
43
45
48
-5
-2
0
2
4
6
8
10
12
14
16
18
20
75%
21
23
25
27
29
31
33
35
37
39
41
43
45
48
Abbreviations:
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
176
DB:20.8,WB:14 DB:23.3,WB:16
TC PI TC PI
kW kW kW kW
49.3 6.56 58.7 7.90
49.3 6.64 58.7 8.00
49.3 6.71 58.7 8.09
49.3 6.84 58.7 8.20
49.3 6.89 58.7 8.28
49.3 6.99 58.7 8.44
49.3 7.13 58.7 8.57
49.3 7.21 58.7 8.73
49.3 7.32 58.7 8.90
49.3 7.46 58.7 9.07
49.3 7.61 58.7 9.24
49.3 7.75 58.7 9.41
49.3 7.89 58.7 9.61
49.3 7.97 58.7 9.69
49.3 8.17 58.7 10.34
49.3 8.70 58.7 11.04
49.3 9.29 58.7 11.77
49.3 9.89 58.7 12.56
49.3 10.53 58.7 13.41
49.3 11.18 58.7 14.28
49.3 11.89 58.7 15.18
49.3 12.65 58.7 16.17
49.3 13.43 58.7 17.18
49.3 14.06 58.7 17.81
49.3 14.69 58.7 18.44
49.3 15.52 58.7 19.27
49.3 16.21 58.7 19.95
37.0 4.47 44.3 5.25
37.0 4.51 44.3 5.27
37.0 4.53 44.3 5.34
37.0 4.56 44.3 5.37
37.0 4.62 44.3 5.50
37.0 4.69 44.3 5.60
37.0 4.78 44.3 5.76
37.0 4.88 44.3 5.85
37.0 5.00 44.3 5.93
37.0 5.08 44.3 6.04
37.0 5.16 44.3 6.16
37.0 5.24 44.3 6.27
37.0 5.33 44.3 6.38
37.0 5.38 44.3 6.43
37.0 5.46 44.3 6.54
37.0 5.58 44.3 6.82
37.0 5.91 44.3 7.26
37.0 6.27 44.3 7.70
37.0 6.62 44.3 8.17
37.0 7.04 44.3 8.70
37.0 7.45 44.3 9.22
37.0 7.87 44.3 9.77
37.0 8.34 44.3 10.35
37.0 8.70 44.3 10.72
37.0 9.41 44.3 11.45
37.0 9.62 44.3 11.70
37.0 9.80 44.3 11.77
Indoor temperature(°C DB/WB)
DB:25.8,WB:18 DB:27,WB:19
TC PI TC PI
kW kW kW kW
68.3 9.41 73.0 10.07
68.3 9.51 73.0 10.26
68.3 9.61 73.0 10.39
68.3 9.72 73.0 10.52
68.3 9.86 73.0 10.68
68.3 9.99 73.0 10.87
68.3 10.17 73.0 10.99
68.3 10.34 73.0 11.18
68.3 10.53 73.0 11.38
68.3 10.73 73.0 11.61
68.3 10.96 73.0 11.83
68.3 11.15 73.0 12.06
68.3 11.49 73.0 12.67
68.3 11.92 73.0 13.13
68.3 12.76 73.0 14.06
68.3 13.66 73.0 15.07
68.3 14.59 73.0 16.11
68.3 15.58 73.0 17.21
68.3 16.62 73.0 18.36
68.3 17.72 73.0 19.60
68.3 18.90 73.0 20.90
68.3 20.14 71.7 21.63
68.3 21.44 70.6 22.37
68.3 22.22 69.6 22.52
68.3 22.63 68.5 22.78
68.3 23.02 67.0 23.10
68.3 23.05 64.2 23.36
51.3 5.94 55.0 6.37
51.3 5.98 55.0 6.50
51.3 6.10 55.0 6.62
51.3 6.20 55.0 6.74
51.3 6.34 55.0 6.86
51.3 6.50 55.0 7.08
51.3 6.64 55.0 7.19
51.3 6.82 55.0 7.34
51.3 6.96 55.0 7.48
51.3 7.07 55.0 7.59
51.3 7.20 55.0 7.76
51.3 7.34 55.0 7.89
51.3 7.48 55.0 8.03
51.3 7.54 55.0 8.12
51.3 7.70 55.0 8.39
51.3 8.20 55.0 8.97
51.3 8.75 55.0 9.55
51.3 9.30 55.0 10.19
51.3 9.91 55.0 10.82
51.3 10.54 55.0 11.51
51.3 11.18 55.0 12.26
51.3 11.90 55.0 13.00
51.3 12.61 55.0 13.83
51.3 12.98 55.0 14.29
51.3 13.52 55.0 15.05
51.3 13.80 55.0 15.30
51.3 13.97 55.0 15.56
DB:28.2,WB:20 DB:30.7,WB:22
TC PI TC PI
kW kW kW kW
77.7 10.93 87.3 12.46
77.7 11.08 87.3 12.60
77.7 11.18 87.3 12.81
77.7 11.31 87.3 13.00
77.7 11.45 87.3 13.13
77.7 11.62 87.3 13.31
77.7 11.81 87.3 13.52
77.7 12.03 87.3 13.75
77.7 12.25 87.3 14.00
77.7 12.48 87.3 14.28
77.7 12.73 86.8 14.45
77.7 12.99 85.8 14.93
77.7 13.92 84.5 15.63
77.7 14.39 84.0 16.00
77.7 15.43 82.9 16.73
77.7 16.53 81.6 17.46
77.7 17.69 80.3 18.20
77.4 18.79 79.3 18.96
76.4 19.52 78.0 19.69
75.1 20.25 76.9 20.42
73.8 20.98 75.6 21.18
72.7 21.74 74.6 21.94
71.4 22.48 73.3 22.67
70.9 22.82 72.0 23.21
70.4 23.04 72.4 23.36
70.0 23.46 71.8 23.72
69.9 23.88 67.4 23.97
58.6 6.80 65.6 7.78
58.6 6.92 65.6 7.90
58.6 7.05 65.6 8.06
58.6 7.17 65.6 8.24
58.6 7.33 65.6 8.37
58.6 7.50 65.6 8.52
58.6 7.66 65.6 8.76
58.6 7.87 65.6 8.94
58.6 8.01 65.6 9.11
58.6 8.14 65.6 9.28
58.6 8.31 65.6 9.44
58.6 8.45 65.6 9.63
58.6 8.61 65.6 9.83
58.6 8.70 65.6 9.97
58.6 9.14 65.6 10.68
58.6 9.74 65.6 11.43
58.6 10.41 65.6 12.20
58.6 11.07 65.6 13.00
58.6 11.79 65.6 13.86
58.6 12.56 65.6 14.77
58.6 13.36 65.6 15.73
58.6 14.22 65.6 16.75
58.6 15.10 65.6 17.80
58.6 15.56 65.6 18.54
58.6 16.02 65.6 19.21
58.6 16.81 65.6 20.26
58.6 17.28 65.6 21.20
Table continued on next page ...
DB:32,WB:24
TC PI
kW kW
92.3 13.00
92.3 13.08
92.3 13.23
92.3 13.44
92.3 13.59
92.3 13.79
92.3 14.02
92.3 14.22
91.0 14.34
89.9 14.51
88.6 14.68
87.6 15.04
86.3 15.77
85.8 16.14
84.5 16.87
83.4 17.60
82.1 18.36
81.1 19.10
79.8 19.86
78.7 20.62
77.4 21.35
76.1 22.11
75.1 22.90
74.0 23.37
72.7 23.63
71.2 23.95
69.7 24.17
72.9 8.95
72.9 9.07
72.9 9.19
72.9 9.34
72.9 9.56
72.9 9.74
72.9 9.93
72.9 10.05
72.9 10.24
72.9 10.43
72.9 10.63
72.9 10.85
72.9 11.15
72.9 11.54
72.9 12.37
72.9 13.22
72.9 14.13
72.9 15.10
72.9 16.09
72.9 17.17
72.9 18.30
72.9 19.49
72.9 20.76
72.9 21.68
72.9 22.35
72.9 23.21
72.9 23.78
