Declaration of conformity
Trade Name:
Model Name:
Responsible Party:
Address:
Telephone:
Facsimile:
Equipment Classification:
Type of Product:
Manufacturer:
Address:
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions : (1) this device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Tested to comply with FCC standards.
Signature :
QDI Computer ( U. S . A. ) Inc.
PlatiniX 1D
QDI Computer ( U. S. A.) Inc.
41456 Christy Street
Fremont, CA 94538
(510) 668-4933
(510) 668-4966
FCC Class B Subassembly
Mainboard
Quantum Designs (HK) Inc.
20th Floor, Devon House, Taikoo Place
979 King’s Road, Quarry Bay, HONG
KONG
Date :
2001
Advertisement
Table of Contents
Related Manuals for QDI PlatiniX 1D Series
Summary of Contents for QDI PlatiniX 1D Series
- Page 1 Declaration of conformity Trade Name: QDI Computer ( U. S . A. ) Inc. Model Name: PlatiniX 1D Responsible Party: QDI Computer ( U. S. A.) Inc. Address: 41456 Christy Street Fremont, CA 94538 Telephone: (510) 668-4933 Facsimile: (510) 668-4966...
-
Page 2: Table Of Contents
C O N T E N T S C O N T E N T S C O N T E N T S C O N T E N T S C O N T E N T S 1. - Page 3 Advanced Chipset Features Setup.........29 Power Management Setup..........31 PNP/PCI Configuration Setup...........34 Integrated Peripherals.............35 PC Health Status..............38 Password Setting............40 Boot with BIOS defaults..........40 Appendix ..............41 QDI Driver Utility CD ............41 LogoEasy.................42 RecoveryEasy..............43 BIOS-ProtectEasy............51 Norton AntiVirus..............51 ManageEasy..............52 SpeedEasy ..............53 BootEasy.................55 StepEasy II(optional)............58 Installation Guide(French)..........60...
- Page 4 Note: This manual is suitable for mainboards of PlatiniX 1D se- ries. Each mainboard is carefully designed for the PC user who wants diverse features. P1D: without onboard Audio and onboard LAN P1D-A: with onboard Audio P1D-L: with onboard LAN P1D-AL: with onboard Audio and onboard LAN Caution...
-
Page 5: Introduction
Chapter 1 Chapter 1 Introduction Overview PlatiniX 1D series mainboard utilizes Intel 845DDR chipset, 845DDR consists of two ® components: the 82845 Memory Controller Hub(MCH) and the 82801BA I/O Controller Hub2(ICH2), providing a fully compatible, high performance and cost-effective mATX platform. - Page 6 Introduction USB Ports 2 USB Host Controllers with total of 4 ports !" USB 1.1 compliant "!" Supports wake-up from S1 (power on suspend), S3 (Suspend to RAM,depends on "! device) Onboard I/O ″ ″ One floppy port supporting up to two 3.5 or 5.25 floppy drives with 360K/720K/1.2M/ "!"...
- Page 7 Supports system monitoring(monitors CPU and system temperatures, system voltages, " !" fan speed) Providing QDI innovations such as SpeedEasy, RecoveryEasy, BIOS-ProtectEasy(to "!" protect the system BIOS from being attacked by severe virus such as CIH ), LogoEasy, ManageEasy, BootEasy,StepEasy II(optional)
- Page 8 T-- This page is intentionally left blank --his...
-
Page 9: Installation Instructions
Chapter 2 Chapter 2 Installation Instructions This section covers External Connectors and Jumper Settings. Refer to the mainboard layout chart for locations of all jumpers, external connectors, slots and I/O ports. Further- more, this section lists all necessary connector pin assignments for your reference. The particular state of the jumpers, connectors and ports are illustrated in the following fig- ures. -
Page 10: Line-In, Microphone-In, Speaker-Out Jacks And Midi/Joystick Connector(Optional)
Installation Instructions Line-in jack, Microphone-in jack, Speaker-out jack and MIDI/Joystick (available on P1D-A,P1D-AL) Connector The Line-in jack can be connected to devices such as a cassette or minidisc player to playback or record. The Microphone-in jack can be connected to a microphone for voice input. The Speaker-out jack allows you to connect speakers or headphones for audio output from the internal amplifier.The MIDI/Joystick connector allows you to connect a game joystick or a MIDI device. -
Page 11: Atx12V Power Supply Connector & Power Switch(Power_Sw)
(if one is provided), then push once the power switch. When powering off the system, you needn’t turn off the mechanical switch, just Push once the power switch. PlatiniX 1D series mainboard only support ATX12V power. +12V... -
Page 12: Speaker Connector (Speaker)
Installation Instructions Speaker Connector (SPEAKER) The connector can be connected to the speaker on the case. Power LED Connector (PWR LED) When the system is in S0 status, the LED is on. When the system is in S1 status, the LED is blink;... -
Page 13: Infrared Header (Irda)
Chapter 2 Infrared Header (IrDA) This connector supports wireless transmitting and receiving. Before using this function, configure the settings for IR Address, IR Mode and IR IRQ from the “INTEGRATED PERIPH- ERALS” section of the BIOS. IRRX IRTX Audio Connectors (CD_IN1, CD_IN2, MODEM) (Available on P1D-A/AL) CD_IN1 and CD_IN2 are Sony standard CD audio connectors, they both can be con- nected to a CD-ROM drive through a CD audio cable. -
Page 14: Smart Card Reader Connector(Scr)
Installation Instructions Smart Card Reader Connector( SCR )(Optional) The SCR Interface Connector is the interface between the motherboard and the Smart Card. The SCR includes a standard UART to control Smart Card interface handshaking and then performs data transfers. The SCR can be used for a broad range of applications in GSM, ID, pay TV, banking and so forth. -
Page 15: Wake-Up On Lan (Wol)
Chapter 2 Wake-Up On LAN (WOL) Through the Wake-Up On LAN function, a wake event occurring from the network can wake up the system. If this function is to be used, please be sure an ATX12V power, and a LAN adapter which supports this function is used. Then connect this header to the relevant connector on the LAN adapter, set “Wake-Up by Ring/ LAN”... -
Page 16: Sound Connector (Pc-Pci)
If the cased has been opened , the system will record the status and indicate the chassis has been opened. You can receive this information from QDI ManageEasy software. Indicate signal... -
Page 17: Pin Smbus Connector(Smbus)
Chapter 2 4 Pin SMBus Connector(SMBUS) This connector allows you to connect SMBus devices. SMBus devices communicate through the SMBus with an SMBus host and/or other SMBus devices. The SMBus or System Management Bus is a specific implementation of I C bus, which is a multi-master bus, that is, multiple chips can be connected to the same bus and each one can act as a master by initiating data transfer. -
Page 18: Audio Interface(Optional)
Installation Instructions Audio Interface (Optional) The audio interface can provide 3 kinds of Audio output choics :the FrontAudio, the RearAudio and the ActiveAudio. Their priority level is as sequence. when the FrontAudio is available, the RearAudio and the ActiveAudio(in-case speaker)will be cut off. when the RearAudio is available, the ActiveAudio will be cut off. -
Page 19: Intruder Detect Switch (Jintr)
Chapter 2 Intruder Detect Switch(JINTR)(Reserved) The connector connects to the chassis security switch on the case. The system can detect the chassis intrusion through the status of this connector. Indicate signal Main Expansion Slots and Connectors Slot/Port (Quantity) Description PCI( 3 ) PCI slots CNR( 1 ) CNR slot... - Page 20 Installation Instructions Jumper Settings Jumpers are located on the mainboard, they represent, clear CMOS jumper JCC, enable BIOS Protection function jumper JAV etc. Pin 1 for all jumpers are located on the side with a thick white line ( Pin1→ ), refer to the mainboard’s silkscreen.
- Page 21 Chapter 2 Enable keyboard password power-on function (JKB) The mainboard provides the advanced keyboard password power-on function. Before using this function, set JKB with pin1 & pin2 closed. Otherwise, set JKB with pin2 & pin3 closed for disabling. Disable: (Default) Enable: Furthermore in order to implement this function, set “POWER ON Function”...
- Page 22 Installation Instructions Clear CMOS (JCC) If you want to clear CMOS, unplug the AC power supply first, close JCC (pin1 & pin2) once, set JCC back to the normal status with pin2 & pin3 connected, then power on the system. Normal status: (Default) Clear CMOS:...
- Page 23 Chapter 2 Enable Front/Back Panel USB Device Wake-up Function (JFUSB/JUSB) The mainboard provides the advanced USB device wake-up function. The system can be waked up from its power saving including ACPI S3 by activating USB device. Before using this function, set JFUSB/JUSB with pin1 & pin2 closed. Otherwise, set JFUSB/JUSB with pin2 &...
- Page 24 Installation Instructions Enable/Disable onboard LAN (JLAN) (Available on P1D-L/AL) This Jumper allows you to use the onboard LAN function. Before using this function,set JLAN with pin1 and pin2 closed.Otherwise set JLAN with pin2 and pin3 closed for disabling. Disable: JLAN Enable: JLAN Wake-Up On LAN (JP5)
