Return to Flow Display
When all settings are as desired return to the Flow Display
screen by pressing the menu button again and selecting Flow
Display.

5.5 CALIBRATION

NOTICE
NOTICE
The Calibration screen is used to calibrate the SHO-FLOW in
the event of incorrect readings. The SHO-FLOW is shipped from
the factory calibrated. Calibration is not required under normal
circumstances.
If you wish to return to this screen
press the Menu button.
Then press the Calibration button.
If calibration needs to be adjusted the user can navigate to the
Calibrations page by selecting the menu button followed by
pressing the Calibration button.
• Follow the directions and enter the measured pressure readings.
Note: If the pressure reading is out of range adjust the valve until you get a reading in the range to activate
calibration option.
• Always calibrate for both the low and high end fl ows to ensure the best possible accuracy.
©Copyright Task Force Tips LLC 2019
Only qualifi ed personnel should perform calibration on a SHO-FLOW.
SHO-FLOW accuracy is dependent on the accuracy of the gage used to perform calibration.
