FOR INSTALLATION WITH
30886 Rail Kit
CAUTION: Under no circumstances do we recommend exceeding the towing vehicle manufacturers
recommended vehicle towing capacity
READ ALL INSTRUCTIONS BEFORE STARTING THE INSTALLATION OR USE
Equipment Required:
Fastener Kit:
Wrenches/ Sockets: 21mm, Torx Plus 60IP, 24EP TORX Plus
Other Tools: Torque Wrench, Ratchet
VEHICLE FORWARD
1. Installation ---------------------------- p 1
2. Assembly and Installation ------- p 2 - 4
©
2019 Horizon Global America Inc.
Product Instructions
Bracket-Ford SD Dual Whl
Or the lowest rated component of your system.
,
1
2
FIG. 1
Table of Contents
Page 1 of 5
3. Maintenance ------------------------------- p 6
4. Warranty ------------------------------------ p 7
308862N
Part Number:
308862
#
Description
QTY
1
Driver Side
Bracket
2
Passenger
Side Bracket
3
Existing
Underbed
3
04/03/2019
Rev. A
1
1
1
Advertisement
Related Manuals for Reese Bracket-Ford SD Dual Whl
Summary of Contents for Reese Bracket-Ford SD Dual Whl
- Page 1 Product Instructions Part Number: 308862 Bracket-Ford SD Dual Whl FOR INSTALLATION WITH 30886 Rail Kit CAUTION: Under no circumstances do we recommend exceeding the towing vehicle manufacturers recommended vehicle towing capacity Or the lowest rated component of your system. READ ALL INSTRUCTIONS BEFORE STARTING THE INSTALLATION OR USE...
- Page 2 Product Instructions Part Number: 308862 Bracket-Ford SD Dual Whl FOR INSTALLATION WITH 30886 Rail Kit ASSEMBLY AND INSTALLATION The Pickup bed must be removed to install this kit. Pickup Bed Removal Remove the tailgate from the pickup bed. Open the tailgate.
- Page 3 Product Instructions Part Number: 308862 Bracket-Ford SD Dual Whl FOR INSTALLATION WITH 30886 Rail Kit ASSEMBLY AND INSTALLATION Remove the rear outer frame bracket bolts and the rear inner bracket rail mounting bolts as shown below (Figure 4). FIGURE 4 Place the correct bracket over the rail as shown and reinstall all hardware (Figure 5).
- Page 4 Product Instructions Part Number: 308862 Bracket-Ford SD Dual Whl FOR INSTALLATION WITH 30886 Rail Kit ASSEMBLY AND INSTALLATION Reinstall the pickup bed. Pickup Bed Installation Install pickup bed Ensure the locating pins shown in figure 6 are properly installed to both the pickup frame and pickup bed to •...
- Page 5 Product Instructions Part Number: 308862 Bracket-Ford SD Dual Whl FOR INSTALLATION WITH 30886 Rail Kit LIMITED LIFETIME WARRANTY Horizon Global Corporation. (“We” or “Us”) warrants to the original consumer purchaser only (“You”) that the product will be free from material defects in both material and workmanship, ordinary wear and tear expected; provided that installation and use of the product is in accordance with product instructions.
