Parameter
On-board Debugger Sleep
8
Current Consumption
Minimum Board Current
Consumption
Note:
1. From EFM32BG22 data sheet
2. From VEML6035 data sheet
3. From Si7021-A20 data sheet
4. From Si7210 data sheet
5. From SPK0641HT4H-1 data sheet
6. From ICM-20648 data sheet
7. From MX25R8035F data sheet
8. From EFM32GG12 data sheet
silabs.com | Building a more connected world.
Symbol
I
On-board debugger current consumption when USB cable
DBG
is not inserted (EFM32GG12 EM4S mode current con-
sumption)
I
Minimum total board current consumption for VMCU = 3.0
BOARD
V with EFR32BG22 in EM4S, the USB cable disconnec-
ted, and all peripherals either in sleep mode or disconnec-
ted
UG464: Thunderboard™ EFR32BG22 User's Guide
Condition
Specifications
Typ
Unit
80
nA
0.4
µA
Rev. 1.0 | 8
