- Page 1 Operati ng manual air / water Heat PumPs Compact LwC series We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH Translation of the original instruction manual...
-
Page 2: Please Read First
€ Indicates suggestions that help to save energy, raw materials and costs. Reference to other sections of the operating manual. Reference other documents manufacturer. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 3: Table Of Contents
Wire mesh grille and weather/rain guards assembly ..17 INSTAllATIoN / coNNecTIoN To HeATING cIRcUIT ............18 manometer ................19 discharge hot water safety valve and condensate discharge ................19 HoT-WATeR TANK ..............20 We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 4: Intended Use
The unit bears the ce mark of conformity. ec declaration of conformity CautIon. For safety reasons: never disconnect the unit from the power supply, unless the unit is being opened. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 5: Customer Service
Install the heat pump so that the air blower does not blow in the direction of footpaths. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 6: Functioning Principle Of Heat Pump System
€ When letting in fresh air, do not leave windows open for an extended period, thus saving energy and reducing your heating costs. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 7: Care Of The Unit
It is a good idea to have a maintenance contract with a specialist company. The company will conduct the required maintenance at regular intervals. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 8: Scope Of Delivery
(lWc 100 and lWc 120) overview “Technical data / scope of delivery”, “Sound” section. for the scope of delivery, see overview “Technical data / scope of delivery”. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 9: Installation Location
To do so, loosen the quick-release screws. Turn transport. counter-clockwise 90°. CautIon. Do not damage the hydraulic connections under any circumstances. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 10: Installation
Tip the unit slowly and carefully to one side… Secure unit in raised position so that it cannot accidentally tip back into the original position. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 11: Installation Of The Ventilation Duct
Remove the side panel on the top left and right by Then tighten the lock nuts. unscrewing the 2 screws on each side… We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... - Page 12 We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH...
-
Page 13: The Air Duct System 700 (Accessory)
If necessary, they are available in lengths of 450 mm or 1000 mm as well as in angled elbow form. Snap-in area at the top We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 14: Product Advantages
Use the lubricant supplied upon delivery to help in this process… Stabilise the wall duct from the inside using the chipboard included with delivery… We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 15: Air Ducts Assembly
1 wall duct 2 air duct 3 roll seal 4 betonite waterstop tape (attach only after assembling the unit's connection fastener) We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 16: Securing The Air Duct On The Heat Pump
Repeat – the process on the air output side. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 17: Wire Mesh Grille And Weather/Rain Guards Assembly
Set the weather / rain guards on the assembly frame in the wall duct and screw down… We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 18: Installation / Connection To Heating Circuit
(return flow) on the heat pump side with the included shut-off devices and flexible hoses… notICe. these are included in the scope of delivery. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 19: Manometer
2 Hose for condensate discharge CautIon! guide the pre-mounted hose in the unit for condensate discharge in the interior of the unit as a siphon. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 20: Hot-Water Tank
(accessory) in the return flow must be mounted in connection with the multifunction tank. “Hydraulic connection” instructions. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... - Page 21 “dimensional drawing” for the respective model. The wires inside the unit are guided in a closed wire duct to the switch cabinet… We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH...
-
Page 22: Rinsing, Filling And Bleeding The System
Ers. d. notICe. rinse heat pump and heating circuit for close electrical switch cabinet of unit. about 5 minutes. lWc 100 1 filling and emptying valve We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... - Page 23 If no further steps follow, install the bottom front panel. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH...
- Page 24 1 minute… lWc 120 1 bleed valve 1 switching valve We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH...
-
Page 25: Insulating The Hydraulic Connections
– clockwise = increases spread. – counterclockwise = decreases spread. open valves to heating circuit. Reset the heating and heat pump regulator. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 26: Installation Of The Control Element
4 hooks are located on the back side of the control control element… element and can be used to hang the control element on the front facade of the unit: We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 27: Installation And Removal Of The Screen
1 recess for control element 2 logo 3 temporary cover first, insert the screen below, in the provided slots on the front of the facade… We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 28: Commissioning
Send completion report for heat pump systems remove the snap-in lugs from the opposite side. and general checklist to the manufacturer’s factory customer service department. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 29: Safety Temperature Limiter
Dispose of battery and electronic compo- nents in keeping with environmental con- siderations. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 30: Technical Data / Scope Of Delivery
*) depending on components tolerances and flow **) comply with local regulations n.n. = not detectable w.w. = to choice ¹) hot water return ²) hot water flow We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... - Page 31 • ı 18 ı 1,5 • ı 24 ı 1,5 • ı 24 ı 1,5 • • • • • • • • 813089a 813090 813083-g 813082-g We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH...
-
Page 32: Performance Curves
Coefficient of performance / efficiency rating ∆p” Freie Pressung Heizkreis Free compression, heating circuit ∆p” Verdichter Compressor(s) We reserve the right to modify technical specifications without prior notice. Leistungs-Druckverlustkurven Bezeichnung: UK830504/210627 © Alpha-InnoTec GmbH Änd./Ä.M./Ersteller/Datum LWC60 Seite: 1/1 - / PEP003-2008 / Opel / 28.11.08... -
Page 33: Lwc80
Coefficient of performance / efficiency rating ∆p” Freie Pressung Heizkreis Free compression, heating circuit ∆p” Verdichter Compressor(s) We reserve the right to modify technical specifications without prior notice. Leistungs-Druckverlustkurven Bezeichnung: UK830504/210627 © Alpha-InnoTec GmbH Änd./Ä.M./Ersteller/Datum LWC80 Seite: 1/1 - / PEP003-2008 / Opel / 17.11.08... -
Page 34: Lwc 100
Coefficient of performance / efficiency rating ∆p” Freie Pressung Heizkreis Free compression, heating circuit ∆p” Verdichter Compressor(s) We reserve the right to modify technical specifications without prior notice. Leistungs-Druckverlustkurven Bezeichnung: UK830504/210627 © Alpha-InnoTec GmbH Änd./Ä.M./Ersteller/Datum LWC100 Seite: 1/1 - / PEP010-2006 / Rüttinger / 18.01.07... -
Page 35: Lwc 120
Coefficient of performance / efficiency rating ∆p” Freie Pressung Heizkreis Free compression, heating circuit ∆p” Verdichter Compressor(s) We reserve the right to modify technical specifications without prior notice. Leistungs-Druckverlustkurven Bezeichnung: UK830504/210627 © Alpha-InnoTec GmbH Änd./Ä.M./Ersteller/Datum LWC120 Seite: 1/1 - / PEP010-2006 / Rüttinger / 17.12.07... -
Page 36: Dimensional Drawings
Attention: included in the scope of delivery 3x flexible hose + 3x ball valve for LWC 60 - LWC 100: R 1" AG DIN 2999 for LWC 120: R 5/4" AG DIN 2999 We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH Zust. -
Page 37: Installation Plan Version 1
If the distances are reduced to the minimum dimension, the air ducts must be made shorter. This leads to a significant increase in the sound intensity level! Zust We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 38: Installation Plan Version 2
If the distances are reduced to the minimum dimension, the air ducts must be made shorter. This leads to a significant increase in the sound intensity level! Zust. Ä We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 39: Installation Plan Version 3
If the distances are reduced to the minimum dimension, the air ducts must be made shorter. This leads to a significant increase in the sound intensity level! We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 40: Installation Plan Version 4
If the distances are reduced to the minimum dimension, the air ducts must be made shorter. This leads to a significant increase in the sound intensity level! We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 41: Installation Plan Version 5
If the distances are reduced to the minimum dimension, the ≈ Kippmaß der Wärmepumpe 2000mm air ducts must be made shorter. This leads to a significant increase in the sound intensity level! Zust. Ä We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 42: Installation Plan Version 6
If the distances are reduced to the minimum dimension, the air ducts must be made shorter. This leads to a significant increase in the sound intensity level! Zust. Ä We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 43: Terminal Diagram
LwC 60 – LwC 120 3~N/PE/400V/50Hz 3~N/PE/400V/50Hz 3~/PE/400V/50Hz 1~N/PE/230V/50Hz B10 A ZW2/SST We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... - Page 44 LwC 60 – LwC 80 Circuit diagram 1/3 We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH...
- Page 45 Circuit diagram 2/3 LwC 60 – LwC 80 We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH...
- Page 46 LwC 60 – LwC 80 Circuit diagram 3/3 yellow white Green Brown We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH...
-
Page 47: Lwc 100 - Lwc 120
Circuit diagram 1/3 LwC 100 – LwC 120 We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... - Page 48 LwC 100 – LwC 120 Circuit diagram 2/3 We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH...
- Page 49 Circuit diagram 3/3 LwC 100 – LwC 120 yellow white Green Brown We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH...
-
Page 50: Ec Declaration Of Conformity
EN ISO 13857 EN 61000-3-2/-3-3 * pressure equipment Component Category Module Designated position: TÜV-SÜD Industrie Service GmbH (Nr.:0036) Company: Place, date: Kasendorf, 20.08.2010 Signature: Jesper Stannow UK818142a Technical Director We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... -
Page 51: General Checklist
Sending the general checklist and the completion report also serves as a request for a technician authorized by the manufacturer to commission your heat pump. We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH... - Page 52 We reserve the right to modify technical specifications without prior notice. UK830504/210627 © Alpha-InnoTec GmbH...
-
Page 53: Completion Report For Heat Pump Systems
Completion report in de: Alpha-InnoTec customer service department 01803 003550 (0,09 €/min. aus dt. festnetz, mobilfunkpreise können abweichen) in AT: Alpha-InnoTec customer service department 0820 500644 (0,15 €/min. aus dem festnetz und mobilfunk) Completion report and request for faCtory Commissioning during factory commissioning, the system will be inspected to ensure that it is functioning properly. This ensures that all factory specifi cations have been checked and that the system can operate reliably over an extended period. -
Page 54: Customer Service
Customer service addresses in the event of a serviCe Call for a current list and additional partners of the manufacturer, please visit www.alpha.innotec.com. Suisse romande ASAp energy SI energiesysteme GmbH Alpha-InnoTec Schweiz AG Tinggaardvej 7 Hubertusgasse 10 ch. de la venoge 7 6400 Sønderborg 2201 Hagenbrunn 1025 St. Sulpice Tel.:... - Page 55 Naas Road Alpha-InnoTec Norge AS ekoenergija d.o.o. muirfield drive, Naas Road, Gamle forusveien 51b mače 6 dublin 12 4033 Stavanger 4205 preddvor Tel.: +353 (0) 141 919 19 Tel.: +47 (0) 51 6605 95 Tel.: +386 (0) 42 555 780...
