AuCom Modbus RTU Card Instructions Manual page 7

Register Description
30605 Current
30606 Current
30607 Motor
temperature
30608 Power
30609 % Power factor
30610 Voltage
30611 Current
30612 Current
30613 Current
30614 Voltage
30615 Voltage
30616 Voltage
30617 Parameter list
version number
Modbus RTU Card (710-16499-00B)
Bits Details
7 Command source
0 = Remote Keypad, Digital Inputs, Clock
1 = Network
8 0 = Parameter(s) have changed since last
parameter read
1 = No parameters have changed
9 0 = Negative phase sequence
1 = Positive phase sequence
Reserved
10 to 15
0 to 13 Average rms current across all three phases
Reserved
14 to 15
0 to 9 Current (% motor FLC)
Reserved
10 to 15
0 to 7 Motor thermal model (%)
Reserved
8 to 15
0 to 11 Power
12 to 13 Power scale
0 = Multiply power by 10 to get W
1 = Multiply power by 100 to get W
2 = Power (kW)
3 = Multiply power by 10 to get kW
Reserved
14 to 15
0 to 7 100% = power factor of 1
Reserved
8 to 15
0 to 13 Average rms voltage across all three phases
Reserved
14 to 15
0 to 13 Phase 1 current (rms)
Reserved
14 to 15
0 to 13 Phase 2 current (rms)
Reserved
14 to 15
0 to 13 Phase 3 current (rms)
Reserved
14 to 15
0 to 13 Phase 1 voltage
Reserved
14 to 15
0 to 13 Phase 2 voltage
Reserved
14 to 15
0 to 13 Phase 3 voltage
Reserved
14 to 15
0 to 7 Parameter list minor revision
8 to 15 Parameter list major version
INSTRUCTIONS
7
