Upload single parameter to starter
Write Parameter 16 (2I
Message Starter Address Function Code
In
Out
Upload multiple parameters to starter
Write Parameters 9, 10, 11 (parameters 2B
Current Limit
). Set to values of 15 seconds, 300%, 350% respectively.
Message Starter Address Function Code
In
Out
NOTE
This function can only be used to upload consecutive parameters. The
Register field indicates the number of parameters to be uploaded, and the
register number of the first parameter.
4.8 Trip Codes
Trip Description
Code
0 No trip
1 Excess start time
2 Motor overload
3 Motor thermistor
4 Current imbalance
5 Frequency
6 Phase sequence
7 Instantaneous overcurrent
8 Power loss
9 Undercurrent
10 Heatsink overtemperature
11 Motor connection
12 Input A trip
13 FLC too high
14 Unsupported option (function not available in inside delta)
15 Communications card fault
16 Forced network trip
17 Internal fault
18 Overvoltage
19 Undervoltage
23 Parameter out of range
Modbus RTU Card (710-16499-00B)
Stop Mode
), set = 1
20 06
20 06
20 16
20 16
Register
40024
40024
Start Ramp Time
, 2C
Register
40017,3 15, 300, 350 CRC1, CRC2
40017,3 15, 300, 350 CRC1, CRC2
INSTRUCTIONS
Data CRC
1 CRC1, CRC2
1 CRC1, CRC2
Initial Current
, 2D
Data CRC
