INSTRUCTIONS
Status Reporting Registers (Read Only)
NOTE
For models EMX4x-0064B and smaller (soft starter model ID 1~4), the current
reported via communications registers is 10 times greater than the actual
value.
Register Description
Reserved
30003
Reserved
30004
Reserved
30005
Reserved
30006
Reserved
30007
Reserved
30008
30600 Version
30601 Model number
30602
Changed
parameter
number
30603 Changed
parameter value
30604 Starter state
6
Bits Details
0 to 5 Binary protocol version
6 to 8 Parameter list version number
9 to 15 Product type code:
12 = EMX4e
13 = EMX4i
Reserved
0 to 7
8 to 15 Soft starter model ID
0 to 7 0 = No parameters have changed
1~255 = Index number of the last parameter
changed
8 to 15 Total number of parameters available in the
starter
0 to 15 Value of the last parameter that was changed,
as indicated in register 30252
Reserved
0 to 4 0 =
1 = Ready
2 = Starting
3 = Running
4 = Stopping
5 = Not ready (restart delay, restart
temperature check, run simulation, reset input
is open)
6 = Tripped
7 = Programming mode
8 = Jog forward
9 = Jog reverse
5 1 = Warning
6 0 = Unintialised
1 = Initialised
