Register Description
40605 Current
40606 Current
40607 Motor
temperature
40608 Power
40609 % Power factor
40610 Voltage
40611 Current
40612 Current
40613 Current
40614 Voltage
40615 Voltage
40616 Voltage
40617 Parameter list
version number
Modbus RTU Card (710-16499-00B)
Bits Details
8 0 = Parameter(s) have changed since last
parameter read
1 = No parameters have changed
9 0 = Negative phase sequence
1 = Positive phase sequence
Reserved
10 to 15
0 to 13 Average rms current across all three phases
Reserved
14 to 15
0 to 9 Current (% motor FLC)
Reserved
10 to 15
0 to 7 Motor thermal model (%)
Reserved
8 to 15
0 to 11 Power
12 to 13 Power scale
0 = Multiply power by 10 to get W
1 = Multiply power by 100 to get W
2 = Power (kW)
3 = Multiply power by 10 to get kW
Reserved
14 to 15
0 to 7 100% = power factor of 1
Reserved
8 to 15
0 to 13 Average rms voltage across all three phases
Reserved
14 to 15
0 to 13 Phase 1 current (rms)
Reserved
14 to 15
0 to 13 Phase 2 current (rms)
Reserved
14 to 15
0 to 13 Phase 3 current (rms)
Reserved
14 to 15
0 to 13 Phase 1 voltage
Reserved
14 to 15
0 to 13 Phase 2 voltage
Reserved
14 to 15
0 to 13 Phase 3 voltage
Reserved
14 to 15
0 to 7 Parameter list minor revision
8 to 15 Parameter list major version
