Figure 8. Confirm Amplifier Output Mode Selection Dialog Box
Click Yes to confirm the amplifier output mode selection and apply it to the amplifier.
4.
ATTENTION:
• Verify output connector wiring and speaker configuration to avoid damage to the speakers and/or amplifier
malfunction prior to clicking Yes.
• Vérifiez le câblage du connecteur de sortie et la configuration du haut-parleur pour éviter les dommages aux haut-
parleurs et/ou au dysfonctionnement de l'amplificateur avant de cliquer sur Oui.

Downloading and Installing Dante Controller

From www.extron.com, hover over the Download tab at the top of the page.
1.
From the Featured Software list, select Dante Controller. The Dante Controller product page opens.
2.
Click the blue Download button.
3.
Select Run to run the Dante Controller installer or select Save to save the install file to run at a later time.
4.
If you choose to run the file, follow all prompts. If you saved the file, click the saved file to begin installation when ready.
NOTE:
The installed Dante Controller program files are saved in
C:\Program Files (x86)\Audinate\Dante Controller\DanteController.exe
Configure Dante Device Settings
Dante settings in the NetPA U 2002 SB can be configured from DSP Configurator. The device can be named in the Dante
Device Settings, which assists with identifying a specific device in the Dante Controller software when there are multiple
devices on the Dante network.
ATTENTION:
• It is crucial that a Dante device be named before audio subscriptions with other devices are established. Existing
subscriptions are removed when a unit is renamed.
• Il est crucial qu'un appareil Dante soit nommé avant la création d'abonnements audio avec d'autres appareils. Les
abonnements existants sont supprimés lorsqu'une unité est renommée.
To configure Dante device settings:
Open DSP Configurator and connect live to the NetPA U 2002 SB.
1.
Select Tools > Device Settings. The Device Settings dialog box opens.
2.
From the tabs at the top of the Device Settings dialog box, select Dante Device.
3.
In the Device Name field, give the NetPA U 2002 SB a name (recommended to be device model and location) so that it can
4.
be easily identified in Dante Controller. No spaces are allowed in the name.
Dante device network settings can also be configured in this dialog box. Use the radio buttons and text fields to choose
5.
DHCP (recommended) or Static IP and enter a static IP address configuration.
Click Apply.
6.
OK
Click to confirm changes and close the
7.
:
Device Settings
dialog box.
.
7
