NetPA U 2002 SB • Setup Guide (Continued)
Bridge Plate Rack Mounting (Side-by-Side)
The NetPA U 2002 SB ships with a bridge plate connector to connect two amplifiers together and form full-rack width unit. Mount
and connect two amplifiers as follows:
If the amplifier has its rubber feet installed, remove them.
1.
Position two amplifiers upside down and side-by-side as shown below.
2.
Use the bridge plate connector and the four provided #4 machine screws to connect the two units together (
3.
Attach the two short rack ears to the units with the four provided #6 machine screws (
4.
Insert the amplifier into the rack and align the holes in the rack ears with the holes on the rack.
5.
Secure the amplifier to the rack using the four provided 10-32 x 3/4" screws (
6.
Figure 2. NetPA U 2002 SB Bridge Plate Rack Mounting
Ventilation Recommendation
Excessive heat decreases the optimal lifetime of the power amplifier.
An Over Temp LED indicator on the front panel of the amplifier lights
red when the recommended operating temperature has been exceeded.
The NetPA Ultra amplifiers need to be arranged in a rack environment, so
that the environment around the amplifier does not reach or exceed +122
°F (+50 °C). No more than four amplifiers should be stacked without a
ventilation opening between the groups.
The NetPA U 2002 SB can also be arranged above or below a non-NetPA
Ultra device, but in any case, the environment should never reach or exceed
+122 °F (+50 °C).
Step 2 — Captive Screw Audio Cable Wiring
Wire the captive-screw connectors to the input or output as shown in the
following figures.
