StakMax Microplate Handling System User Guide
Electrical Safety
To prevent electrical injuries and property damage, inspect all electrical equipment before
use and report all electrical deficiencies. Contact Molecular Devices technical support for
equipment service that requires the removal of covers or panels.
To prevent electrical shock, use the supplied power cord and connect to a properly
grounded wall outlet.
1311 Orleans Drive, Sunnyvale
CA 94089 408 747-1700
The power port is on the right side of the instrument.
+ 24 VDC
Item
1
2
3
To ensure sufficient ventilation and provide access to disconnect power from the
instrument, maintain a 20 cm to 30 cm (7.9 in. to 11.8 in.) gap between the rear of the
instrument and the wall.
Power off the instrument when not in use.
6
WARNING! HIGH VOLTAGE.
electrical shock hazard existing from a high voltage source. Read and understand
all safety instructions before you install, maintain, and service the instrument.
+24V
3A
USB
2
1
Description
Power port for connection to the power supply
USB port for connection to the computer
RS-232 serial port for connection to a microplate washer
Within the instrument is the potential of an
RS-232
3
