GP-XGT (RS232)
Technical Support Manual
© Copyright Reserved Autonics Co., Ltd.
iii

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP Series and is the answer not in the manual?

Questions and answers

Related Manuals for Autonics GP Series

Summary of Contents for Autonics GP Series

  • Page 1 GP-XGT (RS232) Technical Support Manual © Copyright Reserved Autonics Co., Ltd.
  • Page 2 © Copyright Reserved Autonics Co., Ltd.

  • Page 3: Preface

    Preface Preface Thank you very much for selecting Autonics products. Please familiarize yourself with the information contained in the Safety Precautions section before using this product. This user manual contains information about the product and its proper use, and should be kept in a place where it will be easy to access.

  • Page 4: Technical Support Manual Guide

    (www.autonics.com) to download a copy.  The manual's content may vary depending on changes to the product's software and other unforeseen developments within Autonics, and is subject to change without prior notice. Upgrade notice is provided through our homepage. ...

  • Page 5: Technical Support Manual Symbols

    Failure to follow instructions can result in serious injury or death. Failure to follow instructions can lead to a minor injury or product damage. An example of the concerned feature's use. Annotation mark. ※1 © Copyright Reserved Autonics Co., Ltd.

  • Page 6: Safety Precautions

    This product uses lithium battery, do not disassemble or burn up. Failure to follow this instruction may result in explosion or fire.  Wire properly after checking power terminal polarity. Failure to follow this instruction may result in fire or product malfunction © Copyright Reserved Autonics Co., Ltd.
  • Page 7 © Copyright Reserved Autonics Co., Ltd.
  • Page 8 Safety Precautions  Note that this device is KCC certified for commercial use. Make proper applications for the product.. © Copyright Reserved Autonics Co., Ltd.

  • Page 9: Table Of Contents

    Numeral input ..................... 23 3.4.3 Touch key (Up key) ..................24 3.4.4 Touch key (Down key) ................25 3.4.5 Lamp ......................26 3.4.6 Touch key (Reset key) ................27 Appendix ....................29 Serial setting ...................... 29 © Copyright Reserved Autonics Co., Ltd.
  • Page 10 Table of Contents © Copyright Reserved Autonics Co., Ltd.

  • Page 11: System

    V4.01 (build 023) — GP-S070 Firmware V1.20 Release : 2016.01.26 Ms Windows Windows 7 — XG 5000 V4.07 Release : 2016.03.29 Connections GP-S070-T9D6 XGK-CPUE, XGL-CH2A/B Communication cable connection and dimensions (communication cable model: C3M5P01-D9F0-D9M0) © Copyright Reserved Autonics Co., Ltd.
  • Page 12 1 System © Copyright Reserved Autonics Co., Ltd.

  • Page 13: Gp-S070 Communication Setting

    2nd At GP/PLC Type dialog box, set GP/LP Type and CH1/2 Group/Type. Item Setting GP / LP Type GP-S070 T9D6 LS XGT SERIES / CH1 Group / Type XGK_EXT_Cnet CH2 Group / Type No Use © Copyright Reserved Autonics Co., Ltd.
  • Page 14 2 GP-S070 Communication Setting 3rd At Project Auxiliary Property dialog box, click ‘OK’ and it changes screen to draw. © Copyright Reserved Autonics Co., Ltd.

  • Page 15: Gp-S070 Setting

    2 GP-S070 Communication Setting GP-S070 Setting 1st Touch top-left of the GP. 2nd Touch ‘Environment’. 3rd Touch ‘Serial Communication’. © Copyright Reserved Autonics Co., Ltd.
  • Page 16 5th Touch right ‘SET’ and set as below. Item Setting Note Baud rate 19200 User setting Flow control XON/XOFF Don’t care Parity bit None User setting Data bit 8-bit User setting Stop bit 1-bit User setting © Copyright Reserved Autonics Co., Ltd.

  • Page 17: Xgt Setting

    1st Run XG5000 and select [Project] – [New Project] on menu. Enter project name and select CPU type at ‘New Project’ dialog box. 2nd Set connection method at [Online] – [Connection Settings]. This example is connection via USB. After connecting, click [Online] – [Change Mode] – [Stop]. © Copyright Reserved Autonics Co., Ltd.
  • Page 18 3rd Enter [Online] – [Diagnosis] – [I/O Information] and click [I/O Sync]. When I/O synchronizing is completed, it sets as same as the using module. 4th When I/O synchronizing is completed, you can check the added communication module below standard network. Double-click the displayed communication module at right. © Copyright Reserved Autonics Co., Ltd.
  • Page 19 Terminating Disable Fixed resistances Station No. User setting Operation Channel 1 XGT server Mandatory mode 6th At advanced settings, set as below. Item Channel 1 Data bit Advanced Stop bit settings Parity bit NONE © Copyright Reserved Autonics Co., Ltd.
  • Page 20 2 GP-S070 Communication Setting 7th Select [Online] – [Connect Settings] and set connection settings for PC and PLC connection. 8th Download it via [Online] – [Write]. © Copyright Reserved Autonics Co., Ltd.

  • Page 21: Examples

    Counter present value — ① Numeral input Counter target value — ② Touch key Input (Up) — ③ (momentary) Touch key Input (Down) — ④ (momentary) Lamp Counter output ⑤ Touch key Reset — ⑥ (momentary) © Copyright Reserved Autonics Co., Ltd.

  • Page 22: Gp Editor Drawing

    3 Examples GP Editor Drawing 3.4.1 Numeral display Select [Draw]–[Numeral Display] at menu. Click ‘Device’ to set the device as below. Items Setting Channel [CH1]XGK_EXT_Cnet Station Device © Copyright Reserved Autonics Co., Ltd.

  • Page 23: Numeral Input

    3 Examples 3.4.2 Numeral input Select [Draw]–[Numeral Input] at menu. Click ‘Device’ to set the device as below. Items Setting Channel [CH1]XGK_EXT_Cnet Station Device © Copyright Reserved Autonics Co., Ltd.

  • Page 24: Touch Key (Up Key)

    3 Examples 3.4.3 Touch key (Up key) Select [Draw]–[Touch Key]–[Action]–[Bit]. Click ‘Device’ to set the device as below. Items Setting Channel [CH1]XGK_EXT_Cnet Station Device Action Momentary © Copyright Reserved Autonics Co., Ltd.

  • Page 25: Touch Key (Down Key)

    3 Examples 3.4.4 Touch key (Down key) Select [Draw]–[Touch Key]–[Action]–[Bit]. Click ‘Device’ to set the device as below. Items Setting Channel [CH1]XGK_EXT_Cnet Station Device Action Momentary © Copyright Reserved Autonics Co., Ltd.

  • Page 26: Lamp

    3 Examples 3.4.5 Lamp Select [Draw]-[Lamp]. Click ‘Device’ to set the device as below. Items Setting Channel [CH1]XGK_EXT_Cnet Station Device © Copyright Reserved Autonics Co., Ltd.

  • Page 27: Touch Key (Reset Key)

    3 Examples 3.4.6 Touch key (Reset key) Select [Draw]–[Touch Key]–[Action]–[Bit]. Click ‘Device’ to set the device as below. Items Setting Channel [CH1]XGK_EXT_Cnet Station Device Action Momentary © Copyright Reserved Autonics Co., Ltd.
  • Page 28 3 Examples © Copyright Reserved Autonics Co., Ltd.

  • Page 29: Appendix

    Setting at Item Setting at GP-S070 GP Editor CH1 comm. setting Avaliable Avaliable CH2 comm. setting Unavailable Avaliable 1st Check the settings; Application of serial port, setup, menu key, configuration at [Common]- [Auxiliary Configuration]-[Project]. © Copyright Reserved Autonics Co., Ltd.
  • Page 30 4 Appendix 2nd At [Serial Port] tab, set CH1 port configuration. 3rd At [Setup] tab, set CH1 port, station settings. For CH2, the left port is automatically alloted. © Copyright Reserved Autonics Co., Ltd.
  • Page 31 4 Appendix © Copyright Reserved Autonics Co., Ltd.
  • Page 32 4 Appendix © Copyright Reserved Autonics Co., Ltd.
