  • Page 1 User Manual for Communication GP/LP Series (OMRON) Thank you for purchasing an Autonics product. This user manual contains information about the product and its proper use, and should be kept in a place where it will be easy to access. www.autonics.com...
  • Page 2 © Copyright Reserved Autonics Co., Ltd.

  • Page 3: Preface

    Preface Preface Thank you for purchasing Autonics product. Please familiarize yourself with the information contained in the Safety Considerations section before using this product. This user manual contains information about the product and its proper use, and should be kept in a place where it will be easy to access.

  • Page 4: User Manual Guide

    (www.autonics.com) to download a copy.  The manual’s content may vary depending on changes to the product’s software and other unforeseen developments within Autonics, and is subject to change without prior notice. Upgrade notice is provided through our website. ...

  • Page 5: User Manual Symbols

    Failure to follow instructions can result in serious injury or death. Failure to follow instructions can lead to a minor injury or product damage. An example of the concerned feature’s use. Annotation mark. ※1 © Copyright Reserved Autonics Co., Ltd.

  • Page 6: Reference Manual For Each Configuration

    GP-A Series User Manual, LP-A Series User Manual Hardware GP-S070 User Manual, GP-S044/057 User Manual, Manual S Series LP-S070 User Manual, LP-S044 User Manual Check connectable device, connection cable model name and protocol Communication Manual GP/LP Communication Manual © Copyright Reserved Autonics Co., Ltd.

  • Page 7: Table Of Contents

    2.3.6 Available Device ..................３６ 2.3.7 Monitorable Device in GP/LP ..............３７ OMRON Temperature Controller Connection ..........３８ 2.4.1 Connection Support Products ..............３８ 2.4.2 Connectable GP/LP Model ..............３８ 2.4.3 System Organization ................３８ © Copyright Reserved Autonics Co., Ltd.

  • Page 8: Table Of Contents

    Table of Contents 2.4.4 Communication Cable ................３８ 2.4.5 Communication Configuration ..............３９ 2.4.6 Available Device ..................４０ 2.4.7 Monitorable Device in GP/LP ..............４１ viii © Copyright Reserved Autonics Co., Ltd.

  • Page 9: System Organization

    1 System Organization System Organization GP/LP can be connected with various controller, barcode reader and printer via RS232C, RS422, Ethernet, CAN amd USB HOST port. © Copyright Reserved Autonics Co., Ltd.

  • Page 10: 1:1 Communication

    GP/LP-A104 Link device communication available ※1 Ethernet port, CAN port ※2 ※1: Please refer to ‘GP Editor User Manual’ for Link device instruction. ※2: Only Autonics’ ARD Series can be connected to CAN port. © Copyright Reserved Autonics Co., Ltd.

  • Page 11: 1:N Communication Of Same Controllers

    The GP/LP observes the connected controllers or relays data between controllers. A GP/LP can communicate with the multiple of controller As. The controller has to be able to set address of each device, and the address should not be duplicated. © Copyright Reserved Autonics Co., Ltd.
  • Page 12 ※1 Ethernet port, CAN port ※2 ※1: Please refer to ‘GP Editor User Manual’ for Link device instruction. ※2: Only Autonics’ ARD Series can be connected to CAN port. (2) RS422 communication connection diagram © Copyright Reserved Autonics Co., Ltd.

  • Page 13: 1:N Communication Of Different Controllers

    RS232C or RS232C-B port, GP/LP-A104 Link device※1 communication available Ethernet port, CAN port ※2 ※1: Please refer to ‘GP Editor User Manual’ for Link device instruction. ※2: Only Autonics’ ARD Series can be connected to CAN port. © Copyright Reserved Autonics Co., Ltd.

  • Page 14: 1:1:N Communication

    Link device multiple communication GP-S057 RS422/RS485 available Single direct communication available ※ 1 RS232C Link device single communication available CH1 or GP/LP-S070 Multiple direct communication available RS422/RS485 ※ 1 Link device multiple communication available © Copyright Reserved Autonics Co., Ltd.
  • Page 15 ※1 Ethernet port, CAN port ※2 ※1: Please refer to ‘GP Editor User Manual’ for Link device instruction. ※2: Only Autonics’ ARD Series can be connected to CAN port. (2) RS422 communication connection diagram © Copyright Reserved Autonics Co., Ltd.

  • Page 16: N:1:N Communication

    GP/LP-A104 Link device communication available ※1 Ethernet port, CAN port ※2 ※1: Please refer to ‘GP Editor User Manual’ for Link device instruction. ※2: Only Autonics’ ARD Series can be connected to CAN port. © Copyright Reserved Autonics Co., Ltd.

  • Page 17: Barcode Reader, Printer Communication

    Barcode reader ○ ○ GP/LP-A Series  Communication port Connected Series device USB Host RS232C RS422 ※ ※ Controller ○ ○ GP/LP-A070 GP/LP-A104 Barcode reader ○ ○ ○ ※RS232C/422 converter allows to opposite communication. © Copyright Reserved Autonics Co., Ltd.
  • Page 18 ○ GP/LP-S044, GP-S057 Printer ○ ○ Controller ○ ○ GP/LP-S070 Printer ○ ○ GP/LP-A Series  Communication port Connected Series device USB Host RS232C RS422 ※ ※ Controller ○ ○ GP/LP-A070, GP/LP-A104 Printer ○ © Copyright Reserved Autonics Co., Ltd.
  • Page 19 (3) Communication specification Item Specification Baud rate 300, 600, 1200, 3200, 4800, 9600, 19200, 38400, 57600 bps Data length 7, 8 bit Parity None, Odd, Even Stop bit 1, 2 bit Flow control DSR/DTR, XON/XOFF © Copyright Reserved Autonics Co., Ltd.
  • Page 20 1 System Organization © Copyright Reserved Autonics Co., Ltd.

  • Page 21: Communication Configuration By Devices

    SYSMAC C Series executes RS232C commnication with GP/LP by Tool Port. It executes also RS-422 communication with RS-232/422 converter. 2.1.4 Communication Cable (1) Connecting to GP/LP Use CQM1-C1F02 cable by OMRON to connect. (2) Using extension cable  Applied cable: C3M5P12-D9F0-D9M1 © Copyright Reserved Autonics Co., Ltd.

  • Page 22: Communication Configuration

    Bit address 0 to 15 Bit address (Decimal) Word address None (Decimal) Word address None (Decimal) Word address None (Decimal) Word Word address None (Decimal) Word address None (Decimal) Word address (Decimal) Word address (Decimal) © Copyright Reserved Autonics Co., Ltd.
  • Page 23 Read, Write available DM1000 DM1021 Save error code and time DM1022 DM1023 Read, Write available DM6144 DM6599 Read only DM6600 DM6655 Read only For further details of this function, refer to the specific PLC manual. © Copyright Reserved Autonics Co., Ltd.

  • Page 24: Monitorable Device In Gp/Lp

    Memory protection relay Special relay Special relay Link relay Word Timer/Counter current value DM16 Data register 16 bit 32 bit type combining designated number of DM32 Data register device and next number of device © Copyright Reserved Autonics Co., Ltd.

  • Page 25: Omron Sysmac Cs/Cj/Cp Plc Connection

    ○ ○ ○ ○ CP1E × × ○ ○ ○ ○ ○ ○ ○ CP1H × × ○ ○ ○ ○ ○ ○ ○ CP1L × × ○ ○ ○ ○ ○ ○ ○ © Copyright Reserved Autonics Co., Ltd.

  • Page 26: System Organization

    System Organization Communication module (RS-232C/RS422) SYSMAC CS/CJ/CP Series executes RS232C/RS422 commnication by Tool Port with GP/LP. 2.2.4 Communication Cable (1) RS232C Please produce the cable as below. (2) RS422 Please produce the cable as below. © Copyright Reserved Autonics Co., Ltd.

  • Page 27: Communication Configuration

    (1) Change Tool Port setting Connect CX-Programmer and PLC. Select [Setting] of Workspace Window in the left side of CX-Programmer. In [Host Link Port] of opened dialogue box, configure communication settings and unit number. © Copyright Reserved Autonics Co., Ltd.
  • Page 28 Select [I/O Table or Unit setting] of Workspace Window in the left side of CX-Programmer. Select the communication module to change communication settings. Select [Host Link Settings] parameter group of each communication module by port, configure communication settings and unit number. © Copyright Reserved Autonics Co., Ltd.

  • Page 29: Available Device

    None Word address None (Decimal) Word address None (Decimal) Word address None (Decimal) Word address None (Decimal) Word Word address None (Decimal) Word address None (Decimal) Word address None (Decimal) Word address None (Decimal) © Copyright Reserved Autonics Co., Ltd.
  • Page 30 Counter Area C0255 DM Area DM00 DM081915 CIO Area IO00 IO0289 Work Area W099 Holding Bit Area H049 Auxiliary Bit Area A753 Word Timer Area T0255 Counter Area C0255 DM Area DM00 DM0819 Data Register © Copyright Reserved Autonics Co., Ltd.
  • Page 31 DM Area DM00 DM3276715 CIO Area IO00 IO6143 Work Area W511 Holding Bit Area H511 Auxiliary Bit Area A447 Word Timer Area T4095 Counter Area C4095 DM Area DM00 DM32767 Data Register DR00 DR15 © Copyright Reserved Autonics Co., Ltd.

  • Page 32: Monitorable Device In Gp/Lp

    Note CIO Area Work Area Holding Bit Area Auxiliary Bit Area Timer Area Counter Area DM Area CIO Area Work Area Holding Bit Area Word Auxiliary Bit Area Timer Area Counter Area DM Area © Copyright Reserved Autonics Co., Ltd.

  • Page 33: Omron Sysmac Cs/Cj/Cp Ethernet Communication Module Connection３３

    × × × ○ CJ1H × × × × × × × × ○ CJ1M × × × × × × × × ○ CP1H × × × × × × × × ○ © Copyright Reserved Autonics Co., Ltd.

  • Page 34: System Organization

    Change Tool Port setting Connect CX-Programmer and PLC. Select [I/O Table and Unit Setup] of Workspace Window in the left side of CX-Programmer.. Select Ethernet Communication module which connected to PLC, when I/O setting window displays. © Copyright Reserved Autonics Co., Ltd.
  • Page 35 (XXX.XXX.XXX.to) of the GP/LP to be connected. (must be connected on the same network.) Set ‘Sub-net Mask’ as ‘255.255.255.0’. Set ‘FINS/TCP Port’ as ‘Default (9600)’. In ‘FINS/TCP’ tab, FINS/TCP Connection Setting must be set as ‘Server’. FINS/TCP Please check default setting or corresponding tab. © Copyright Reserved Autonics Co., Ltd.

  • Page 36: Available Device

    Hexadecimal Hexadecimal Hexadecimal Decimal Decimal Decimal Decimal Decimal Decimal Decimal Decimal Hexadecimal Hexadecimal Decimal Decimal Word address (Decimal) Word address (Decimal) Word address (Hexadecimal) Word Word address (Decimal) Word address (Decimal) Word address (Decimal) © Copyright Reserved Autonics Co., Ltd.

  • Page 37: Monitorable Device In Gp/Lp

    2.3.7 Monitorable Device in GP/LP GP/LP is able to monitor PLC device and change the status. The following is avilable device list of this menu, please refer to ‘Available device’ for available device range. © Copyright Reserved Autonics Co., Ltd.

  • Page 38: Omron Temperature Controller Connection

    Omron E5□□ Series executes RS485 commnication. It executes also RS232C commnication with RS485/232 converter. E5AN and E5EN support RS232C communication without converter depending on the model. 2.4.4 Communication Cable (1) RS-485  Applied cable: C3M5P03-D9M0-T4Y0 © Copyright Reserved Autonics Co., Ltd.

  • Page 39: Communication Configuration

    Select protocol Modbus Communication 0 to 99 Enable to set as user-defined station Baud rate 9.6 kbps Communication 8bit data length Stop bit 1bit Parity NONE Waiting time of Display only when transmission © Copyright Reserved Autonics Co., Ltd.

  • Page 40: Available Device

    ※1. It is used device when operating command. Enter the specific value, it executes the below table operation. ※2. Device address is same as each variable of temperature controller. For further details of each variable, refer to the each product manual. © Copyright Reserved Autonics Co., Ltd.

  • Page 41: Monitorable Device In Gp/Lp

    The following is avilable device list of this menu, please refer to ‘Available device’ for available device range. Type Mark Device Note Operation command device Word DM16 Variable device 16 bit 32 bit type combining designated number of DM32 Variable device device and next number of device © Copyright Reserved Autonics Co., Ltd.
  • Page 42 * Dimensions or specifications on this manual are subject to change and some models may be discontinued without notice. MTA-GPLPC_OMRON-V1.0-1907US...
