Operation

8.4.8 Test sequence display

NOTE
Test sequence starts, display shows progress and status.
Green text indicates action required.
Display contents are an example – content and display are based on the test
program used.
Ending a phase early by pressing Continue requires an additional confirmation by
pressing
Yes
If the specified waiting times are not observed, the test sequence is no longer to
standard.
44
in order to proceed to the next phase.
Displays progress, no input
•
possible
Test sequence phase
•
Current test data
•
Current parameters
•
• Waiting time and end time
• Cancel, cancels test
sequence, deletes current
entries and measurement
values, returns to the menu
•
Continue, ends the current
phase of the test sequence
phase early
