ADJUSTABLE FEATURES
SX TRANSISTOR CONTROLS
Range
Set
Example:
FUNCTION 53 MODE 2 CONTROLLED ACCELERATION
(Push CONT 6)
Same as Function 48.
This CONTROLLED ACCELERATION takes effect when the
Mode 2 settings are called for by Function 1.
FUNCTION 54 MODE 2 FIELD WEAKENING START
(Push CONT 7)
Same as Function 49.
This FIELD WEAKENING START takes effect when the
Mode 2 settings are called for by Function 1.
FUNCTION 55 MODE 2 MINIMUM FIELD CURRENT
(Push CONT 8)
Same as Function 50.
This MINIMUM FIELD CURRENT takes effect when the
Mode 2 settings are called for by Function 1.
FUNCTION 56 MODE 2 RATIO
(Push CONT 9)
Same as Function 51.
This RATIO takes effect when the Mode 2 settings are
called for by the Function 1.
FUNCTION 57 MODE 2 REGEN ARMATURE CURRENT
LIMIT
(Push CONT 10)
Same as Function 52.
This REGEN ARMATURE CURRENT LIMIT takes effect when
the Mode 2 settings are called for by Function 1.
FUNCTION 58 MODE 3 CONTROL ACCELERATION
(Push CONT 11)
Same as Function 48.
This CONTROL ACCELERATION takes effect when the Mode
3 settings are called for by Function 1.
FUNCTION 59 MODE 3 FIELD WEAKENING START
(Push CONT 12)
Same as Function 49.
52 to 364 amps
32 to 224
Setting of 50 = 78 amps
This FIELD WEAKENING START takes effect when the
Mode 3 settings are called for by Function 1.
FUNCTION 60 MODE 3 MINIMUM FIELD
(Push CONT 13)
Same as Function 50
.
This MINIMUM FIELD takes effect when the Mode 3
settings are called for by Function 1.
FUNCTION 61 MODE 3 RATIO
(Push CONT 14)
Same as Function 51.
This RATIO takes effect when the Mode 3 settings are
called for by Function 1.
FUNCTION 62 MODE 3 REGEN CURRENT LIMIT
(Push CONT 15)
Same as Function 52.
This REGEN CURRENT LIMIT takes effect when the Mode 3
settings are called for by Function 1.
