4+2 Input HDBaseT Switching Extender with
USB2.0 & Relay Triggering
EX-SW-0401-H2-PRO
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features before beginning the
installation process.
IMPORTANT! Installation Requirements
• Read through the
Wiring and Connections
guidelines before creating or choosing premade cables.
• While this product supports CEC, WyreStorm cannot guarantee
compatibility with all forms of CEC communication.
• Visit the product page to download the latest firmware, document version,
additional documentation, and configuration tools.
Information and Parts Required for Installation
This extender requires connection via RS-232 or Ethernet in order to configure
functions such as EDID. Ensure that the following items are on hand before
proceeding with the installation.
• PC or Mac
• Telnet and Terminal software such as
• USB COM Port Adapter (Not Included)
• WyreStorm Part: CAB-USB-3PIN
• Network router and/or switch if using IP telnet for configuration.
• Latest version of the
EX-SW-0401-H2-PRO API
not covered in this document.
Basic Wiring Diagram
Personal Computer
USB
Mic/Speaker
Deskplate
Laptop
Copyright © 2018 WyreStorm Technologies | wyrestorm.com
EX-SW-0401-H2 Quickstart Guide | 180919
section for important wiring
PuTTY
for advanced configuration
USB Flash Drive
12V DC 1.5A
Power Supply
Local Monitor
In the Box
1x EX-SW-0401-H2-PRO Transmitter
1x EX-SW-0401-H2-PRO Receiver
2x 12V DC Power Supply (US/UK/EU)
1x IR Transmitter
1x IR Receiver
4x Mounting Brackets (2x for TX | 2x for RX)
5x 3-pin Screw Down Phoenix Connector
2x 4-pin Screw Down Phoenix Connector
1x Quickstart Guide (This Document)
Touchscreen
USB Camera
Signage Player
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
1 of 4
Quickstart Guide
Window Blinds
Router
Short Throw
Projector
Interactive
Whiteboard
support@wyrestorm.com
12V DC 1.5A
Power Supply
Amplifier
KEY
HDMI/DisplayPort/USB-C
HDBaseT/Ethernet
RS-232/Relay
Analog Audio
Analog Video
USB 2.0
