3:1 HDMI/VGA/DP Switching Extender with Scaling Receiver,
Relay Triggering and HDCP 2.2
EX-SW-0301-H2
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features before beginning the
installation process.
IMPORTANT! Installation Requirements
This extender requires connection via RS-232 or Ethernet in order to configure
functions such as EDID. Ensure that the following items are on hand before
proceeding with the installation.
• PC or Mac
• Telnet and Terminal software such as
• USB COM Port Adapter (Not Included)
• WyreStorm Part: CAB-USB-3PIN
• Network router and/or switch if using IP telnet for configuration.
• Latest version of the
EX-SW-0301-H2 API
covered in this document.
Basic Wiring Diagram
