Hamlet Solution (S4)
Inset Stove
User Guide
PLEASE RETAIN THIS GUIDE FOR FUTURE REFERENCE
EN 13229:2001 +A2:2004
BK745
Rev 02
ISSUE DATE : 15/09/2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hamlet Solution S4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hamlet Hamlet Solution S4

Summary of Contents for Hamlet Hamlet Solution S4

  • Page 1 Hamlet Solution (S4) Inset Stove User Guide PLEASE RETAIN THIS GUIDE FOR FUTURE REFERENCE EN 13229:2001 +A2:2004 BK745 Rev 02 ISSUE DATE : 15/09/2020...
  • Page 2 Please ensure that you read these instructions in full and understand them before operating your stove. Hamlet stoves, has a policy of continuous product development and therefore we reserve the right to amend specifications without prior notice. Due to printing cycles, items or options may be described before they are generally available or after they have ceased.

  • Page 3: Table Of Contents

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE Contents - 1 Identifying your stove 1.1 Identifying parts & terminology of your stove—External..…………………….. Page 5 1.2 Identifying parts & terminology of your stove—Internal ………………………. Page 6 2 Warnings 2.1 Important Warnings………………………………………………………………..
  • Page 4 Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 7 Further Information For All Stove Owners 7.1 Reduced burning (Slow combustion)………………………………. Page 19 7.2 Over firing……………………………………………………………….. Page 19 7.3 Chimney fires…………………………………………………………… Page 19 7.4 Periods of non-use (Summer months)…………………………….. Page 20 7.5 Riddling the grate …………………………………………………..

  • Page 5: Identifying Your Stove

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 1 Identifying your stove 1.1 Identifying parts & terminology of your stove—External Top Flue Outlet (Inside Builders Opening) Secondary Air Control Fire Door Assembly Fire Door Handle Primary Air Control Builders Opening Joint Line...

  • Page 6: Identifying Parts & Terminology Of Your Stove-Internal

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 1.2 Identifying parts & terminology of your stove—Internal Fire Door Glass Fire Door Handle Grate * Tertiary Air Control (Riddling) Primary Air Control Secondary Air Control Throat Plate **Tertiary Outlet Fuel Retainer...

  • Page 7: Warnings

    Ignoring the warnings could lead to damage/injury to persons and/or property. Hamlet Stoves will not be responsible for any consequential or incidental loss or injury however caused. It is essential that the appliance has adequate air supply for combustion and ventilation.

  • Page 8: Health & Safety

    Hamlet Solution Inset 5 S4 5kW stove—2.5mm Open  Hamlet Solution Inset 7 S4 7kW stove— 2mm Open  Page 8 BK745...

  • Page 9: Recommended Fuels

    It is important to ensure that your fuel is intended for use in a stove or closed appliance. Modern stoves are designed for use with the cleaner burning and smokeless fuels. Hamlet stoves, recommends the use of approved smokeless fuels which have been deemed suitable for use on closed appliances including multi fuel stoves or boilers.

  • Page 10: Pointers Before Use

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 4 Before using your stove 4.1 Pointers Before Use Solution Inset S4 stoves are designed to be operated with the fire door(s) closed at all times, apart from refuelling (when alight) or cleaning (when cold).

  • Page 11: Air Inlet Controls

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 5 Air inlet controls 5.1 Air Inlet Your stove requires air to function, this enters the appliance at 3 points; above the fire door on the front of the stove, via the control bottom front and the two holes beneath the appliance.

  • Page 12: Primary Air Control

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 5.1.2 Primary air control The primary air control regulates the air entering the fire box chamber, suppling air to the under side of the fuel bed. The control has an internal rotary plate with slots, housed inside the body of the appliance and is located centrally below the fire door assembly.

  • Page 13: Tertiary Air

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE The control has an internal sliding plate with slots, housed inside the body of the appliance and is located centrally above the fire door assembly, when looking at the front of the appliance.
  • Page 14 Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 5.1.4 Tertiary Air—Continued For the 5kW version, an adjustment slider is used to ensure the optimum burn performance, please see below for instruction for use: Solid Fuel Burning ONLY Wood Burning...

  • Page 15: Lighting Your Stove

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 6 Lighting your stove 6.1.1 Smoke control areas Please check whether your dwelling is located in a smoke control area before installation or use. Please check with your local authority or https://www.gov.uk/smoke-control-area-rules.

  • Page 16: Burning Solid Fuel

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 6.3 Burning solid fuels Solid fuel burns best with its air supply for combustion coming from underneath the fuel. To achieve this, the burn will be controlled by the primary air control.

  • Page 17: Warning - Fume / Smoke Emissions

     following times, in order to establish good combustion - Hamlet Solution 5kW Inset S4—2 to 3 minutes with the fire door ajar Hamlet Solution 7kW Inset S4 — 3 minutes with the fire door ajar Do not leave the appliance unattended until flames are well established.

  • Page 18: Smoke Control Area

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 6.6 Smoke Control Area (The Clean Air Act 1993 & Smoke Control Areas) If the stove is to be installed in a designated Smoke Control Area (further information can be found via https://www.gov.uk/smoke-control-area-rules ) then the installer will have fitted the a restrictor screw for the secondary air lever to prevent total closure of this air control.

  • Page 19: Further Information For All Stove Owners

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 7 Further information for all stove owners 7.1 Reduced burning (Slow Combustion) When wood is burnt slowly in a closed appliance (eg: air controls at the minimum setting), it produces moisture and tar, which will create condensation and deposits in the chimney.

  • Page 20: Periods Of Non-Use (Summer Months)

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 7.4 Periods of non-use (summer months) Please ensure that your stove is left clean and moving components are well lubricated with a water repelling corrosion inhibitor for the summer months (during periods of prolonged non-use).

  • Page 21: Ash Removal

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 7.6 Ash removal The ash pan should be emptied when the level of ash reaches the top of the ash pan. On no account should the ash be allowed to build up to touch the underside of the grate, as this will greatly reduce the life span of the grate.

  • Page 22: Replacement Parts

    USER GUIDE 7.7 Replacement parts Genuine replacement spare parts can be obtained from your Hamlet stoves retailer /dealer. You can find a complete list of spares and consumables such as liners, replacement grate parts and throat plates as well as items to enhance its visual appearance and efficiency such as stove paint and rope kits.

  • Page 23: Care For Your Stove

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 8 Care for your stove The need for regular maintenance on your stove will ensure, safe and efficient use of your appliance. The following item listing should be checked and inspected by a competent person or engineer on a regular basis.

  • Page 24: Fire Door Seal

    Hamlet Solution Inset (S4) Stove User Guide USER GUIDE 8.4 Fire door seal The rope seal around the edges of the main fire door should also be checked. Look for signs of fraying, peeling away or the ends not meeting. If the rope is unable to create a good seal with the stove body it should be replaced.

  • Page 25: Guarantee

    If any part of the main body of the stove fails due to a manufacturing or material defect during the guarantee period that applies in respect of the relevant stove (as set out below), Hamlet Stoves will, at its sole discretion, repair or replace your stove, for no charge.

  • Page 26: General

    11. The guarantee is only valid where any spare parts used are supplied by Hamlet Stoves or an approved retailer / dealer. The use of spares other than those supplied by Hamlet Stoves shall invalidate the guarantee.

  • Page 27: Technical Data

    Hamlet Solution Inset (S4) Stove User Guide TECHNICAL SPECIFICATION Solution 5kW Solution 7kW TECHNICAL DATA Inset S4 Inset S4 Height (mm) 580 mm 580 mm Width (mm) (Across Canopy & 517 mm 517 mm Riddle Boss) Depth (mm) (Rear To Handle...
  • Page 28 Hamlet Solution Inset (S4) Stove User Guide TECHNICAL SPECIFICATION Solution 5kW Solution 7kW TECHNICAL DATA Inset S4 Inset S4 Nominal Heat Output—Wood (Kw) Efficiency Nett At Nominal Heat 79.9 75.4 Output (%) Mean Flue Gas Temperature (°C) Mean CO Emission @ 13% O2 (%) 0.08...

  • Page 29: Notes

    Hamlet Solution Inset (S4) Stove User Guide NOTES BK745 Page 29...
  • Page 30 Hamlet Solution Inset (S4) Stove User Guide NOTES Page 30 BK745...
  • Page 31 Hamlet Solution Inset (S4) Stove User Guide NOTES BK745 Page 31...
  • Page 32 AFFIX DUPLICATE STOVE DATA LABEL HERE Hamlet is a brand name of Arada Arada Ltd The Fireworks, Weycroft Avenue, Axminster, Devon EX13 5HU United Kingdom www.aradastoves.com www.aradastovesandspares.com T: +44 (0)1297 632 050 All Hamlet Stoves are manufactured in the UK DATE OF ISSUE—15/9/2020 BK 745...
