- Page 1 Operating & Installation Manual Camborne Deluxe RANGE OF STOVES Camborne Deluxe Medium (Pictured) PLEASE RETAIN THIS GUIDE FOR FUTURE REFERENCE Rev 06 BK055 November 2009 Part No. AFS1297...
- Page 2 Should you have any questions about our Camborne Deluxe stoves that are not covered buy our manual, please contact the Hamlet retailer in your area, or call our technical support department on 0844 8475107 Copyright 2008 Arada Ltd...
-
Page 3: Table Of Contents
Building Control Consent Checklist Over Firing & Chimney Fires Ash Removal Air Inlet Controls (Primary / Air wash) Fuel Retainer Bars Multi Purpose Operating Tool 28-29 OPTIONAL EXTRA/ACCESSORIES SPARE PARTS LIST 31-33 GUARANTEE 34-35 FACTORY CHECK LIST Hamlet Camborne Deluxe Stoves... -
Page 4: Warning Notice
MUST NOT BE BURNED IN THIS APPLIANCE BITUMINOUS HOUSE COAL SHOULD NEVER BE USED IN YOUR STOVE TO USE THESE FUELS WILL INVALIDATE THE APPLIANCE GUARANTEE. IF IN DOUBT CONTACT THE SOLID FUEL ASSOCIATION TELEPHONE NUMBER 0845 601 4406 www.solidfuel.co.uk Hamlet Camborne Deluxe Stoves... -
Page 5: Introduction
Hamlet stoves are also fitted with an „air wash‟ Always grip with the palms of your hands so called because it provides a curtain of high... -
Page 6: Check List
2. Grate Bars 3. Throat plate 4. Flue Spigot 1 (4”) 1 (5”) 1 (5”) 1 (6”) 5. Hot Plate 1 (4”) 1 (5”) 1 (5”) 1 (6”) 6. Ash Pan 7. Operating Tool 8. Stove mitten Hamlet Camborne Deluxe Stoves... - Page 7 Camborne Deluxe Deluxe Deluxe Deluxe Part Description & Visual Aid Compact Small Medium Large 9.Rear Liners 10.Side Liners 11. Rear Grate bar support 12. Comb Assembly comprising of comb & comb extension bar 13. Instruction Manual Hamlet Camborne Deluxe Stoves...
-
Page 8: Technical Data
Width (mm) Depth (mm) Height to Centre of Rear Flue (mm) Depth from Back to Centre of Flue (mm) Flue Diameter 102 (4") 127 (5") 127 (5") 152 (6") ( mm / Inches) Weight Packed (Kg) Hamlet Camborne Deluxe Stoves... -
Page 9: Installation
AIR FOR COMBUSTION ASBESTOS There must always be a permanent means of All Hamlet stoves contain no asbestos in their providing air for combustion into the room in which manufacture or construction. If there is a possibility of disturbing any asbestos in the course of the the stove is installed. -
Page 10: Fittting The Flue Outlet & Hotplate
(located on the rear of the appliance) are sealed chimney should be installed in accordance with with fire cement, and thus preventing surplus air Building Regulations and BS 7566: Parts 1 to 4. entering the firebox, resulting in less efficiency and poor fuel consumption. Hamlet Camborne Deluxe Stoves... - Page 11 Details on the relevant Building Regulations and BS British Standards are given in the “ General Precautions” section of these instructions. Chimneys should be as straight as possible. Horizontal runs should be avoided except where Hamlet Camborne Deluxe Stoves...
- Page 12 Minimum 150mm (6”) Diameter Flue Maximum 150mm (6”) Horizontal Flue Section Soot Door Fire Retardant Rope Packing Maximum 100mm (4”) Brick Up Aperture Fill Void TYPICAL REAR FLUE OUTLET (as per BS 8303-1) Hamlet Camborne Deluxe Stoves...
- Page 13 PLAN VIEW OF REGISTER PLATE AND CLEARANCES FOR NON INSULATED FLUES Combustible Register Thick (Plan View Of Steel Register Plate, 1.5mm Plate. Minimum ) Minimum 1.5mm Thick Steel. TYPICAL TOP FLUE OUTLET (as per BS 8303-1) Hamlet Camborne Deluxe Stoves...
-
Page 14: Fitting The Grate
Please see the instructions below on grate assembly. Grate The grates in the Hamlet Camborne Delux stoves, comprise of a series of reciprocating cast iron grate bars, seated on a pivoted „comb‟. All bars in the grate are identical, but every other bar is Fig. -
Page 15: Firebox Liner Panels
INSTALLATION FIREBOX LINER PANELS The Hamlet Camborne Deluxe stoves use firebox liner panels to the sides and back. The throat plate sits on top of the sides and rear panels. These should come fitted to your stove, if however they are not, proceed as follows to fit them. -
Page 16: Final Check
The above details must be checked and the Building Control Checklist on page 17 completed in full by the installer at the time of the installation Please answer all questions as fully as possible. Hamlet stoves cannot be held responsible for the chimney or the installation of the stove. -
Page 17: Building Control Consent Checklist
I/We the undersigned confirm that the above details are correct. In my opinion, these works comply with the relevant requirements in part J of Schedule 1 of the Building regulations. Print name and title…………………………………………………………………..Profession………………………………….. Capacity……………………………………………………………………………...Telephone No. …………………………….. Address………………………………………………………………………………………………..Postcode………………….. Signed………………………………………………………………………………..Date………………………………………... Registered member of..(e.g. CORGI, OFTEC, HETAS, NACE, NACS)…………………………………………………………. Hamlet Camborne Deluxe Stoves... -
Page 18: Service & Maintenance
NACS chimney engineer who will up heat slowly to gradually cure paint. provide a Certificate Of Chimney Sweeping. Note: Use genuine Hamlet touch up spray as some The whole flue way including the outlet must be paints interact. This could ruin the finish and swept at least twice per burning season. -
Page 19: Summer Storage / Non Usage
When the appliance is cold, open the fire door so that it is at right angles to the front of the stove. Lift the fire door up off the hinges. Drop one washer on the top and bottom hinge pins. Hamlet Camborne Deluxe Stoves... -
Page 20: Disassemble The Airwash
SERVICE & MAINTENANCE DISASSEMBLE THE AIRWASH The Hamlet Camborne Deluxe air wash may be disassembled for cleaning or adjustment. To achieve this, the following procedure should be followed : Unscrew (Anti-clockwise) the air wash con- trol knob. (Fig. 11) ... -
Page 21: Fire Door Rope Replacement
Allow 30 minutes, before refitting the door to Note: the appliance. The door pictured is for the single door Compact, the procedure remains the same for all models. Fig. 14. Rope Replacement Fig. 15. Lining Up Gasket Hamlet Camborne Deluxe Stoves... -
Page 22: Disassemble The Primary Air Control
Fig. 16. Positioning The Glass a selected setting by tightening the knob down firmly Fig. 17. Tightening The Glass Clip Please Note- This should be carried out Fig. 18 Primary air inlet slider when the fire is cold and unlit. Hamlet Camborne Deluxe Stoves... -
Page 23: Service Record
Company Work Carried Out Signature Should you have any questions about your Hamlet Camborne Deluxe stove that are not covered in this manual please contact your Hamlet dealer. Please keep all repair receipts safely. Please ensure you have this manual available when an engineer visits so they can complete the service record chart. -
Page 24: Operating Instruction
GLOVES WHEN REFUELLING YOUR STOVE. Use Of Other Fuels. For additional further advise on fuels, please refer to HETAS, Tel 0845 634 5625 or www.hetas.co.uk or Solid Fuel Associa- tion, Tel 0845 601 4406 or www.solid-fuel.co.uk Hamlet Camborne Deluxe Stoves... -
Page 25: Burning Wood / Solid Fuel
In The Morning Open the air controls fully until embers begin to glow brightly and place pieces of fuel on the fire until it is well established. Hamlet Camborne Deluxe Stoves... -
Page 26: Over Firing & Chimney Fires
WARNING : The ash can be very hot. Empty only into a metal container. Even if the ash appears cold, red-hot pieces of ash may be concealed and could easily start a fire or cause an injury Hamlet Camborne Deluxe Stoves... -
Page 27: Air Inlet Controls (Primary / Air Wash)
PRIMARY AIR Air enters the appliance through the control on the bottom of the fire door. The Hamlet Camborne Deluxe has a single control knob which slide left to right. Sliding the knob to the Left (+), see Fig.19, will increase the amount of air intake to the stove. -
Page 28: Multi Purpose Operating Tool
TOOL Empty the ash pan. Your Hamlet stove is supplied with a multi purpose Please Note—Do not force the riddling lever. operating tool, which is used for riddling, setting the grate, adjusting the air inlet controls and the TO EMPTY THE ASH PAN removal of the ash pan. -
Page 29: Main Fire Door Handle
OPERATING INSTRUCTIONS MAIN FIRE DOOR HANDLE A stove mitten is supplied with your Hamlet Camborne Deluxe stove, this is provided for the operation of the fire door handle whilst the stove is in use. Care must be taken when opening and closing the fire door as any surrounding areas of the stove will be very hot. -
Page 30: Optional Extra/Accessories
ECB9 ECB11 Upgrade Kit WBTRAY WBTRAY WBTRAY WBTRAY Note: For ‘Add in Boiler’ information please see additional information sheet BK058 available from your local dealer or Telephone Arada Ltd. on:- Tel: 01297 35596 email to info@arada.uk.com Hamlet Camborne Deluxe Stoves... -
Page 31: Spare Parts List
8. Liner Set AFS1205 AFS1156 AFS1163 AFS1242 AFS1206 AFS1058 AFS1165 AFS1243 9. Side Liner (2 per) (2 per) (2 per) (2 per) AFS1207 AFS1157 AFS1164 AFS1244 10. Back Liner (1 per) (2 per) (2 per) (2 per) Hamlet Camborne Deluxe Stoves... - Page 32 AFS1303 AFS1315 AFS1315 Door Complete 18. Replacement Fire Door locking AFS1298 AFS1304 AFS1304 AFS1304 Assembly 19. Replacement AFS1297 AFS1297 AFS1297 AFS1297 Manual Note 1. The Hamlet Camborne Deluxe Compact model has one Fire Door only (AFS1299) Hamlet Camborne Deluxe Stoves...
-
Page 33: Spare Parts List
Compact Small Medium Large 20. Comb and AFS1274 AFS1276 AFS1291 AFS1301 Extension Bar 21. Grate bar AFS1275 AFS1277 AFS1170 AFS1246 Support 22. Stove Mitten AFS1285 AFS1285 AFS1285 AFS1285 23. Centre Fire Door AFS1469 AFS1469 AFS1469 Rope Hamlet Camborne Deluxe Stoves... -
Page 34: Guarantee
FREE OF CHARGE as long as the When you buy an Hamlet stove, you are not stove has been installed according to this only buying a first class appliance you are... -
Page 35: Guarantee
This guarantee specifically does not cover accidental damage, misuse, wear & tear. The use of non Hamlet replacement parts will invalidate your warranty. For full details, contact your local Hamlet retailer. All guarantees are in addition to your statutory rights. Please see page 34 for further information regarding the lifetime guarantee. -
Page 36: Factory Check List
Ash Pan Operating Tool Operating & Installation Manual Stove Mitten Date of Purchase……………………………….. Name and Address of Supplier……………………………………………. ………………………………………………………………………………… ………………………………………………………………………………... Arada Ltd The Fire Works Weycroft Avenue Axminster Devon EX13 5HU United Kingdom Tel: +44(0)1297 35700 Fax: +44(0)1297 35900 www.arada.uk.com BK055...
