4 - INSTALLAZIONE DEL PRODOTTO

4.1 - Collegamenti elettrici

ATTENZIONE - Prima di effettuare i collegamenti verificare che la centrale non sia alimentata
M2
M1
M1
M2
ECLIPSE
COM
LED
FLASH SEN
6
MODULO DI POTENZA PO24
M2
SBS
GND
COLLEGAMENTI PO24
LS1
Ingresso finecorsa 1
LS2
Ingresso finecorsa 2
Comune finecorsa / positivo alimentazione encoder
V+
(12 Vdc 50 mA MAX)
ENC
Ingresso segnale encoder S
NEG
Negativo alimentazione encoder
M-
Uscita motore
Terra
M+
Uscita motore
COLLEGAMENTI ALIMENTAZIONE
L
Fase alimentazione 230 Vac 50-60 Hz
Terra
N
Neutro alimentazione 230 Vac 50-60 Hz
M
M1
1
2
1 2
3 4
12/24
GND
12/24
COM OUT
_
_
AC/DC
AC/DC
NC
1
TX
RX
PH1
GND
_
2
1 2
3 4
12/24
GND
12/24
COM OUT
_
AC/DC
AC/DC
NC
TX
RX
PH2
TRASFORMATORE
T2A
N
L
