- Page 1 ICMP HDD Installation manual R5905769/00 11/02/2014...
- Page 2 Barco nv Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.36.883.86 Support: www.barco.com/esupport Visit us at the web: www.barco.com Printed in Belgium...
-
Page 3: Disposal Information
Changes Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied warranties or merchantability and fitness for a particular purpose. Barco may make im- provements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice. - Page 4 Barco. If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly, in particular if the systems are commissioned operated incorrectly or if, after the trans- fer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the...
- Page 5 1. ICMP HDD replacement kit 1. ICMP HDD REPLACEMENT KIT Purpose of this kit This kit contains one HDD which can be used to replace a malfunction HDD of the Barco ICMP installed in a Barco DP Infinium powered projector. About this document This document gives a brief introduction into the ICMP HDD, describes the LED status of the HDD and describes the HDD removal and installation instructions.
- Page 6 1. ICMP HDD replacement kit A failed drive should be replaced as soon as possible. AUTION A RAID 5 configuration with three HDDs allows a maximum loss of one disk. With the simultaneous loss of more than one HDDs, data is lost and the RAID must be...
- Page 7 1. ICMP HDD replacement kit Status overview PWR/ERROR and READY LEDs: HDD I/O RAID ICMP HDD Status HDD turned off Blinking RAID normal operation (I/O activity) Green Blinking Blinking Red RAID rebuilding Green RAID error Removing a HDD form the ICMP How to remove a HDD ? 1.
- Page 8 1. ICMP HDD replacement kit Image 1-5 To install the HDD see procedure "Installing a HDD into the ICMP", page 4 . Installing a HDD into the ICMP This procedure assumes that the HDD slot of the ICMP is empty. If not, see procedure "Removing a HDD form the ICMP", page 3 .
- Page 9 1. ICMP HDD replacement kit Image 1-7 4. Push the HDD completely inside its slot, close the handle, and move the latch towards the right. Image 1-8 5. Switch on the projector. In case you replace one HDD (e.g. degraded mode) the ICMP automatically starts with the RAID recovery process.
