- Page 1 Operating and installation instruction book ELECTRIC WATER HEATER Glass-lined Inner tank N° : ___________________________ ____ / ____ / 20___...
- Page 2 kW/24h CAPACI OUTPUT VOLTAGE MAIN (kBт/24h) (kW) (Bт) (V~) /(B~) BOARD (vertical) SQUARE O’PRO ❶&❷ ❸ ❹ ❺ 15 l 2000 0,41 ❶&❷ ❸ ❹ ❺ 30 l 2000 0,56 ❶&❷ ❸ ❹ ❺ 50 l 2000 0,76 ❶ ❷ 1-Hot water tube 2-Safety relief valve 3-Funnel...
- Page 3 ENGLISH (EN) WARNINGS: This device is not intended for use by persons (including children) with physical, sensory or mental disability, or by persons lacking experience or knowledge, unless they have received from a person in charge of their safety adequate supervision or preliminary instructions on how to use the device.
- Page 4 HYDRAULIC CONNECTION: See the general warnings 10 to 14 - All water supply pipes must be thoroughly cleaned before connection. The connection to the hot water outlet must be made using a bimetallic nipple or a plastic dielectric union in order to avoid corrosion of the tubes (due to direct contact between iron and copper).
- Page 5 If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or its service agent. - REPLACEABLE PARTS: the thermostat, seals, heating element, the heating sleeve, the indicator light, the magnesium anode, the connection cable. The guarantee requires genuine manufacturer’s parts to be used.
