OBL X9 Series Operating Manual

Process hydraulic diaphragm metering pumps
Table of Contents

Advertisement

PROCESS
HYDRAULIC DIAPHRAGM
METERING PUMPS
P
O
S
I
T
I
V
E
R
E
T
U
R
N
-
A
P
O
S
I
T
I
V
E
R
E
T
U
R
N
-
A
TRANSLATION OF ORIGINAL INSTRUCTIONS
ATTENTION: Industrial machinery not intended for use by
non-professional operators.
These instructions are intended for qualified personnel.
X
9
X
9
V
E
R
S
I
O
N
V
E
R
S
I
O
N
HYDRAULIC SYSTEM WITH BUILT-IN SAFETY VALVE, MECHANICALLY
ACTUATED OIL REPLENISHING VALVE AND AIR-BLEED VALVE
Doc. N°
UT4336 Rev.
Prepared
E. SERRAINO Checked
Rev.
Revised sections
OPERATING MANUAL
P
I
6
7
5
P
I
6
7
5
Lang.
1st Issue
0
ENG
V. D'ADDIO Replace
14.12.09
UT2694
Checked
Date
English
SERIES
L
OBL
JOB No.
CUSTOMER
CUSTOMER
ORDER No.
METERING
PUMP
TYPE
ANNEXES
ITEM/S
SERIAL
NUMBER/S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X9 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for OBL X9 Series

  • Page 1 SERIES PROCESS HYDRAULIC DIAPHRAGM METERING PUMPS TRANSLATION OF ORIGINAL INSTRUCTIONS ATTENTION: Industrial machinery not intended for use by JOB No. non-professional operators. These instructions are intended for qualified personnel. CUSTOMER CUSTOMER ORDER No. HYDRAULIC SYSTEM WITH BUILT-IN SAFETY VALVE, MECHANICALLY ACTUATED OIL REPLENISHING VALVE AND AIR-BLEED VALVE METERING PUMP...
  • Page 2: Table Of Contents

    Suction pipeline for viscous liquids ....................17 6.2.3 Filter on suction pipeline ......................... 17 DISCHARGE PIPELINE ..........................18 6.3.1 External safety valve ........................19 Page 2 Copyright © - OBL Metering pumps - All rights reserved File: UT-4336 – Rev.0...
  • Page 3 Flow rate irregular or higher than expected ..................36 9.1.3 Overheating of pump body and/or motor ..................36 DISCONNECTION FROM THE PLANT AND SENDING TO OBL FOR MAINTENANCE ......... 36 STORAGE FOR LONG PERIODS ........................ 36 DISPOSAL AND DEMOLITION........................36 10.
  • Page 4: Introduction

    STANDARD operating X9 series pumps are not suitable for use in potentially explosive areas ! WARNING: X9 series pumps for hazardous areas must be especially ordered for said use ! In potentially explosive atmospheres must be used only ATEX execution pumps with a flameproof motor ! All pumps in ATEX execution differ from NON ATEX (or standard execution) pumps in that they are fitted with a second identification plate with specific indication of the data required by the directive.
  • Page 5: Personnel Responsible For Machine Operation

    2.2.2 Guarantee Metering pumps, as with all other OBL products, are guaranteed for a period of twelve (12) months of operation but in any case no longer than eighteen (18) months from the date of delivery (document of transport refers).
  • Page 6: Instructions For Requesting Spare Parts

    INSTRUCTIONS FOR REQUESTING SPARE PARTS Find and study the sectional drawing of the pump in use, if necessary contact OBL to obtain a copy. Analyze the conditions and identify the damaged components. Using the nomenclature of the sectional drawing, make a list of the parts those components (mention the...
  • Page 7: Symbols And Suggestions In These Instructions

    ADDITIONAL NOTE FOR ATEX PUMPS The X9 Series Hydraulic Diaphragm Metering Pumps in ATEX version comply with the rules concerning equipment and protective systems for use in potentially explosive atmospheres in accordance with European Directive 94/9/CE dated 23/03/94, known as ATEX directives.
  • Page 8: Suitability Verification For Effective Application/Use

    – worm wheel internal reduction gear in an oil bath. The mechanically actuated replenishing hydraulic system ("intelligent" diaphragm) makes the diaphragm immune from accidents or mishandling in discharge or suction. Page 8 Copyright © - OBL Metering pumps - All rights reserved File: UT-4336 – Rev.0...
  • Page 9: Identification Nameplate

    ...WA... pneumatic actuator adjustment with manual adjustment ...Z... electric actuator adjustment continue … Motor informations: ...M... motors supplied by OBL and assembled on the pump File: UT-4336 – Rev.0 Copyright © - OBL Metering pumps - All rights reserved Page 9...
  • Page 10: Ambient And Design Temperature

    The pump sectional drawing is usually attached to the present operating manual. In case of it is not attached or missing, see the point "Hydraulic system oil filling" to consult pumphead section drawing or at least contact OBL customer service to receive an updated copy.
  • Page 11: The Flow Rate

    Any other use is considered "IMPROPER USE" and is not allowed. OBL declines all responsibility for any damage to persons or property and any kind of machine guarantee shall be considered void. REASONABLY EXPECTED IMPROPER USE...
  • Page 12: Prohibited Use

    For a correct use of the pump, the user must comply with the power frequency range allowed by OBL, defined and including from 30Hz to 80Hz. Moreover, IT MUST NOT EXCEED the max operating pressure indicated on the pump nameplate. This value is downgraded and takes into account the maximum operating regime at maximum allowable power frequency (80Hz).
  • Page 13: Pumps Type Lk

    All X9 pumps are equipped with an internal safety valve in the hydraulic circuit, located in the expansion tank (see the figures in "Hydraulic system oil filling"). File: UT-4336 – Rev.0 Copyright © - OBL Metering pumps - All rights reserved Page 13...
  • Page 14: Installation And Commissioning

    On the discharge pipeline, to remove easily the pump from the plant, provide proper draining pipes near the pumphead. We suggest to use short fittings to disassemble easily the flanged connections (see figure 4). Page 14 Copyright © - OBL Metering pumps - All rights reserved File: UT-4336 – Rev.0...
  • Page 15: Connecting The Motor To The Mains

    500 l/h < Qmax < 2000 l/h 1-1/2" Ø 40 mm DN 40 1-1/2" ANSI Qmax > 2000 l/h 2" Ø 50 mm DN 50 2" ANSI File: UT-4336 – Rev.0 Copyright © - OBL Metering pumps - All rights reserved Page 15...
  • Page 16: Suction Pipeline Path

    Internal diameter of suction Internal diameter of suction pipeline proportioned (see pipeline inadequate (see previous table A) previous table A) Correct Incorrect Correct Incorrect Page 16 Copyright © - OBL Metering pumps - All rights reserved File: UT-4336 – Rev.0...
  • Page 17: Suction Pipeline For Viscous Liquids

    Incorrect Recommended 6.2.3 Filter on suction pipeline To ensure proper pump operation it is important that the product dosed is liquid, homogeneous and clean. File: UT-4336 – Rev.0 Copyright © - OBL Metering pumps - All rights reserved Page 17...
  • Page 18: Discharge Pipeline

    Discharge pressure must be greater than suction pressure by at least 0,3 bar (0,5 bar for small flow rates). See indications shown in figure 8 for discharge pipeline arrangements. Page 18 Copyright © - OBL Metering pumps - All rights reserved File: UT-4336 – Rev.0...
  • Page 19: External Safety Valve

    The external safety valve pressure opening (calibration) must be lower than the internal of the pump (see nameplate). Figure 9 INCORRECT INSTALLATION CORRECT INSTALLATION Correct Incorrect Safety Valve must be installed BEFORE (upstream) the ON-OFF valve File: UT-4336 – Rev.0 Copyright © - OBL Metering pumps - All rights reserved Page 19...
  • Page 20: Pulsation Dampener

    PULSING flow rate (without pulsation dampener) CONTINUOUS flow rate (with pulsation dampener) Pump working pressure > 1 bar Pump working pressure < 1 bar Page 20 Copyright © - OBL Metering pumps - All rights reserved File: UT-4336 – Rev.0...
  • Page 21: Pressure Gauge

    2 = Calibration pot 6 = ON-OFF valve 3 = External safety valve 7 = Pulsation dampner 4 = Metering pump 8 = Pulsation dampner drain valve File: UT-4336 – Rev.0 Copyright © - OBL Metering pumps - All rights reserved Page 21...
  • Page 22: Electric Motor Installation

    30Hz to 80Hz allowed and defined by OBL correct installation of all possible accessories and their proper operation...
  • Page 23: Checks During Operation

    Each pump is a reliable, quality product, subjected to a thorough final inspection. In case of malfunction, although pump is installed correctly and operating according to the instructions, do not improvise and immediately contact OBL customer service. These maintenance suggestions are not intended as "do-it-yourself" repairs. To perform such works, specialised technical knowledge is required and operations are to be performed by qualified personnel.
  • Page 24: Consulting Technical Documentation

    Page 24 Copyright © - OBL Metering pumps - All rights reserved File: UT-4336 – Rev.0...
  • Page 25: Verification Of Thermal Protections

    Valve housing O-ring Valve (sphere) Diaphragm NOTE * Suggested quantity: SV= Single Valve pumphead (standard OBL); DV= Double Valve pumphead 7.4.2 Pumps with METALLIC material pumphead This list is indicative; we suggest proceeding as detailed in "Instructions for requesting spare parts".
  • Page 26: Personnel Qualifications - Customer Service

    7.5.1 Personnel qualifications - Customer service Entrust the maintenance, repairs and overhauls to experienced and qualified personnel who will restore the original equipment conditions. For information please contact OBL customer service. 7.5.2 Disconnecting electrical connections Before disassembling the pump always disconnect all the electrical connections. Make sure that any risk of accidental restart of the machine has been excluded.
  • Page 27: Pumps Type Lk, Ln, Lp

    ATTENTION: The valve (pos.15) MUST sit on valve seat (pos.5) on the OPPOSITE side of large bevelled surface. Figure 13 LK, LN, LP PUMPS: PUMPHEAD COMPONENTS LUBRICANT OIL CHANGE X9 pumps are always supplied with lubricant oil on the mechanism. File: UT-4336 – Rev.0 Copyright © - OBL Metering pumps - All rights reserved Page 27...
  • Page 28: Special Maintenance

    Appropriate individual safety devices must always be used to ensure and safeguard the personal safety of personnel, who must also be properly trained and professionally qualified. TECHNICAL DOCUMENTATION For "special maintenance" not expected, contact OBL customer care (Tel. +39-02-26919.1, info@obl.it) to receive: detailed and focused informations specific instructions copy (if available)
  • Page 29: Hydraulic Oil System Change

    ATTENTION: The removal of the pumphead causes a loss of hydraulic oil and failure of the whole system ! Carefully assess the actual need for such operation and prepare for oil collection. File: UT-4336 – Rev.0 Copyright © - OBL Metering pumps - All rights reserved Page 29...
  • Page 30 ATTENTION: Correct assembly of the diaphragms and metallic ring is guided by the sides on the pumphead INCORRECT INSTALLATION CORRECT INSTALLATION 14-F 14-E SIDES Page 30 Copyright © - OBL Metering pumps - All rights reserved File: UT-4336 – Rev.0...
  • Page 31: Hydraulic System Oil Filling

    (pos.50) without breaking the seal. In this way it will be easier to expel air from inside the oil chamber (pos.33) ATTENTION: The internal safety valve is setted and sealed by OBL at the end of final testing. Do not remove the seal, do not dismantle the PSV, do not tamper with or, worse, operate directly on the internal components.
  • Page 32 X9 Series metering pumps Operating manual Figure 16 LK PUMPS: PUMPHEAD Page 32 Copyright © - OBL Metering pumps - All rights reserved File: UT-4336 – Rev.0...
  • Page 33: Pumphead Tightening Torque Values

    Define the most appropriate pumphead tightening torque value, considering also the following factors: File: UT-4336 – Rev.0 Copyright © - OBL Metering pumps - All rights reserved Page 33...
  • Page 34: Diaphragm Rupture Detector Resetting

    (pos.150) by screwing, not tightly, the locking dowel (pos.195) reassemble the cap (pos.220) by means of the screws (pos.152). Page 34 Copyright © - OBL Metering pumps - All rights reserved File: UT-4336 – Rev.0...
  • Page 35: Bearings Replacement

    ATTENTION: The internal safety valve is setted and sealed by OBL at the end of final testing. Do not remove the seal, do not dismantle the PSV, do not tamper with or, worse, operate directly on the internal components. These actions could compromise the safety of the plant and of personnel and will also void the guarantee.
  • Page 36: Other Information

    - Low level of lubricant oil or chemically contaminated - Check and if necessary change the lubricant oil DISCONNECTION FROM THE PLANT AND SENDING TO OBL FOR MAINTENANCE BEFORE shipping, always contact OBL customer service and operate as indicated in "Mandatory instruction for returning goods in OBL". STORAGE FOR LONG PERIODS For long term storage (more than 6 months), in addition to those described in "Storage conditions"...
  • Page 37: Mandatory Instruction For Returning Good In Obl

    (authorisation number to return goods to OBL), returning informations and related forms; ALWAYS properly clean ANY pieces of equipment from any residuals of products, to guarantee safety at work for OBL's staff; Duly fill-in the declaration of conformity for shipping and attach it to relevant equipment (we suggest to attach it to shipment documents an insert a copy in the packing);...
  • Page 38 X9 Series metering pumps Operating manual Present information does not replace any existing standard or requirement for safety. OBL declines any responsibility for damages to persons or property. 10.3 GOODS REJECTED TO SENDER If OBL receives the goods: Not properly cleaned (and/or without declaration of conformity for shipping filled-in)
  • Page 39 Operating manual X9 Series metering pumps File: UT-4336 – Rev.0 Copyright © - OBL Metering pumps - All rights reserved Page 39...
