Application Example

The following illustration shows one way to configure a system using the SF 228T Plus.
Extron
SF 228T Plus
Plenum 2' x 2'
Ceiling Speaker
Extron
SF 228T Plus
Plenum 2' x 2'
Ceiling Speaker
Wireless Mic 1
Wireless Mic 2
Figure 1.
SF 228T Plus Application Diagram
2
OVER
TEMP 1 2
LIMITER/PROTECT
SIGNAL
NetPA U 1002 SERIES
Audio Line
Inputs
Extron
WPD 101 3.5 mm
Single Gang
AUDIO
Pass-Through
Wallplate
Ethernet
Audio Line Outs
Assistive Listening
System Transmitter
