Prorack EXP360U Instructions Manual

First Time Installation
• Please read instructions carefully before installation.
• Check the contents of kit. Contact your Prorack dealer if any parts appear to be missing or damaged.
• Clean your roof racks prior to fi tting the roof box.
Important Warning
• It is critical that all Prorack racks and accessories be properly and securely attached to your vehicle. Improper
attachment could result in an automobile accident, and could cause serious bodily injury or death to you or to others.
• You are responsible for securing the racks and accessories to your car, checking the attachments prior to use, and
periodically inspecting the products for adjustment, wear, and damage.
• If you do not understand all of the instructions and cautions, or if you have no mechanical experience and are not
thoroughly familiar with the installation procedures, you should have the product installed by a professional installer
such as a roof rack specialist.
Kit Contents
Item Component
A Roof Box Base
B Roof Box Lid
C Latch Clamp
D Nut Plate
E Lid Lifter Pivot
F Capscrew
G Luggage Strap
H Fitting Kit 1 (SP166)
I Fitting Kit 2 (SP167)
J Allen Key 2.5 mm
K Key Set
L Hole Punch
J
3
2
B
1
A
3
2
B
1
A
K
EXP360U-Rev3.0
Qty
1
1
4
6
2
12
2
1
1
1
1
2
I
3
2
B
1
A
3
2
L
B
1
A
Roof Box 360 L
OPENS
EITHER SIDE
H
G
LENGTH: 145 CM MAX WEIGHT:
WIDTH: 85 CM 50 KG
HEIGHT: 44 CM
WEIGHT: 10.4 KG
EXP360U
A
B
F
E
C
D
Page 1 of 6
