3.3 USE WITH SALT WATER
Use with salt water is permissible provided the monitor is thoroughly cleaned with fresh water after each use. The service life of the
monitor may be shortened due to the effects of corrosion and is not covered under warranty.
3.4 INLET AND OUTLET OPTIONS
Available inlets and outlets are shown below and should be specified at time of order.
61 61
46 2-
21 9-
EL #
M O D
w w w
IA L#
SE R
2.0" BSP
1.5" BSP
FEMALE
FEMALE
(Y1403)
(Y1402)
©Copyright Task Force Tips, Inc. 2017
Note: Outlet thread options are machined into elbow.
Y1 165
®
US A
E IN
M AD
om •
w. tf t.c
• ww
56
12 34
om -Y
.t ft .c
2.0" ANSI 150
(Y1417)
INLET OPTION
2.0" BSP FEMALE (Y1403)
1.5" BSP FEMALE (Y1402)
2.0" ANSI 150 (Y1417)
1.5" ANSI 150 (Y1412)
2.0" NPT FEMALE (Y1401)
1.5" NPT FEMALE (Y1400)
OUTLET OPTIONS
OPTION #
THREAD
1
1.5" NH MALE
2
1.5" NPSH MALE
3
1.5" BSP MALE
1.5" ANSI 150
(Y1412)
Fig 3.4a
Inlets and Outlets
Weight
2.1 lb
0.95 kg
2.1 lb
0.95 kg
3.0 lb
1.4 kg
2.2 lb
1.0 kg
2.1 lb
0.95 kg
2.1 lb
0.95 kg
Figure 3.4b
Inlet Weight
7
ELBOW
Y1311ANF
Y1311AIF
Y1311ABF
2.0" NPT
1.5" NPT
FEMALE
FEMALE
(Y1401)
(Y1400)
