3.2 SPECIFICATIONS

Model Name
Operating Flow Range
Max Flow Range
Min Flow Rate Required to Connect
Waterfl ow Diameter
Flow Accuracy
Non-recoverable Pressure Loss @ Max Flow
Max Operating Pressure
Hydrostatic Test Pressure
Operating Temperature - Electronics
Length
Width
Weight
Materials
IP Rating
Power Supply
Backup Battery
Wireless Communication
Display
Flow Units
Pressure Units

3.3 DEVICE COUPLINGS

The SHO-FLOW is off ered with standard hose threaded connections; 1.5" - 9 NH, 1.5" - 11 BSP, or 1.5" - 11.5 NPSH. Inlets are rigid
female threaded couplings, Fluid is sealed using a hose gasket. Do not use thread sealant. Outlets are rigid male threads. Maximum
torque 20 ft-lb (27 Nm).
Device must be properly connected. Mismatched or damaged threads may cause device to leak or
CAUTION
uncouple under pressure and could cause injury.
Dissimilar metals coupled together can cause galvanic corrosion that can result in the inability
CAUTION
to unscrew the threads or complete loss of thread engagement over time. Per NFPA 1962 (2008
edition), if dissimilar metals are left coupled together an anti-corrosive lubricant should be applied
to the threads. Also, the coupling should be disconnected and inspected at least quarterly.

3.4 USE WITH SALT WATER

Use with salt water is permissible provided the SHO-FLOW fl ow meter is thoroughly cleaned with fresh water after each use. The
service life of the SHO-FLOW may be shortened due to the eff ects of corrosion and is not covered under warranty.
©Copyright Task Force Tips LLC 2019
Device Specifi cations
SHO-FLOW 1
50-300 GPM (200-1150 LPM)
350 GPM (1325 LPM)
50 GPM (200 LPM)
1.5" (38mm)
+/-2.5% Full Scale
15 PSI @ 300 GPM
300 PSI (20 bar)
900 PSI (62 bar)
32 - 140F (0 - 60C)
6.1" (155mm)
3.7" (94mm)
2.6 lbs (1.2 kg)
Aluminum 6000 series hard anodized
MIL8625 class 3 type 2, stainless steel 300
series, POM, nitrile rubber, and CPVC
IP65
Self-powered, Water Flow Energy Harvesting
CR2032 enabled in app
App Specifi cations
Bluetooth® Version 4.1
SHO-FLOW Smart Phone App
GPM, LPM, LPS
PSI, BAR, KPA
5
